Help CenterPaper Bursting Strength Tester China Manufacture
Related Products
Bursting Strength Tester application:
Bursting Strength Tester is used to test the strength and performance of materials like paper, paper boards, corrugated boards and boxes, solid fibre boards, filter cloth, industrial fabrics, leather, rexine, etc.
Bursting Strength Tester features:
1. Digital display pressure
2. Matched motor gives constant pumping rate for better performance, eliminating manual error.
3. Three spare rubber diaphragms and one bottle of hydraulic fluid supplied with machine.
Bursting Strength Tester technical parameter:
Model |
AS-BS-100 |
Sensing Method |
Pressure convertor |
Display Mode |
LED display |
Volume(option)-high Pressure Mode |
0~100kg/cm2(accuracy 0.1kg/cm2) |
Volume(option)-low-pressure Mode |
0~16kg/cm2 (accuracy 0.02kg/cm2) |
Oil-pressure Speed (ml/min) |
170±10 |
Radius of Rim lock-upper Ring(mm) |
high pressure mode Φ31.5, low pressure mode Φ30.48 |
Radius of Rim Lock-lower Ring (mm) |
high pressure mode Φ31.5, low pressure mode Φ31.75 |
Oil Pressure Gauge |
0~25kg/ cm2 0~350lg/cm2 |
Motor |
AC220V |
Dimension WxHxD (mm) |
530x570x235 |
Weight (Kg) |
65 |
Power |
AC220V |
Power Consume |
200W |
Optional Accessories |
Micro-printer |
Bursting Strength Tester pictures:
