Help CenterDAHUA 2.4Megapixel 1080P Vandal-proof IR HDCVI Mini Wedge Dome Camera HAC-HDBW2220F
Related Products
-
Cheap Price DAHUA 2.1Megapixel 1080P Water-proof WDR HDCVI IR60m-Bullet Camera HAC-HFW2221R-Z-IRE6US$ 63 - 66MOQ: 1 Piece -
Dahua Camera 1megapixel hd 720p ip Cctv Mini Dome Security Camera 1080p Video SurveillanceUS$ 1 - 160MOQ: 1 Piece
-
1.0megapxeil Dome Ptz Camera Surveillance Camera Wireless Ptz Cvi CameraUS$ 1 - 160MOQ: 1 Piece
-
AHD Video Surveillance CCTV Security System Cameras,HD CVI CameraUS$ 1 - 160MOQ: 1 Piece
-
Dahua Megapixel Ip66 Zoom ir Dome Auto Surveillance Camera FCC,CE,ROHSUS$ 1 - 200MOQ: 1 Piece
GUOWEI is Dahua authorized company to sale their products to oversea.And we do it for many years.
We supply dahua ip camera, dahua nvr, dahua hdcvi camera/dvr,dahua dvr
Please add +86- 188 7414 0007 to your phone contact & whatsapp
Features
>25/30fps@1080P, 25/30/50/60fps@720P
>High speed, long distance real-time transmission
>HD and SD switchable
>OSD Menu, control over coaxial cable; Build-in MIC
>Day/Night(ICR), AWB, AGC, BLC, 3DNR
>3.6mm fixed lens (2.8mm, 6mm optional)
>Max. IR LEDs length 20m, Smart IR
>IP67, IK10, DC12V
| Model | DH-HAC-HDBW2220FP | DH-HAC-HDBW2220FN |
| Camera | ||
| Image Sensor | 1/2.8" 2.4Megapixel CMOS | |
| Effective Pixels | 1984(H)×1225(V) | |
| Electronic Shutter | 1/3s~1/100,000s | |
| Video Frame Rate | 25/30/50/60fps@720P; 25/30fps@1080P | |
| Synchronization | Internal | |
| Mini. Illumination | 0.05Lux/F1.8, 0Lux IR on | |
| Video Output | 1-channel BNC HDCVI high definition video output/ CVBS standard definition video output (Can switch) Tester out | |
| Camera Features | ||
| Max. IR LEDs Length | 20m, Smart IR | |
| Day/Night | Auto(ICR) / Color / B/W | |
| Noise Reduction | 2D/3D | |
| OSD Menu | Support | |
| Lens | ||
| Focal Length | 3.6mm (2.8mm, 6mm optional) | |
| Angle of View | H: 88º(106º/55º) | |
| Mount Type | M12 | |
| General | ||
| Power Supply | DC12V±20% | |
| Power Consumption | Max 3.3W | |
| Working Environment | -30°C~+60°C / Less than 95%RH (no condensation) | |
| Transmission Distance | Over 500m via 75-3 coaxial cable | |
| Ingress Protection | IP67 & IK10 | |
| Dimensions(W×D×H) | Φ106.3mm×50.3mm | |
| Weight | 0.3kg | |
| Material | Metal | |
| Others | Build-in MIC | |
Technical Highlights
• HD Video format
1920H(1920×1080) & 1280H(1280×720)
• Analog Modulation
Uncompressed and crosstalk-free
• Transmission over coaxial cable
Reliable and non-latency point-to-point transmission
• Auto Compensation & Long range transmission
1280H(1280×720): 500m via Φ75-3, 650m via Φ75-5
1920H(1920×1080): 300m via Φ75-3, 400m via Φ75-5
• Composite video/audio/PTZ signals
HDCVI composites video, audio and PTZ signals together and have them transmitted over coaxial cable.
• Two-way data transmission
CERTIFICATION
GWSECU office building and factory
Attending the fair.
Our products based on the high quality, quality testing superior.
With years of export experience along with excellent quality, advanced services and competitive prices, GWSECU has won numerous customers' trust and support. Welcome to our company
FAQ
1. Payment
What are the terms of payments you offer?
We accept payment via T/T,L/C at sight, Paypal, Westunion etc
2. Shipment
How long will it takes to deliver goods?
We will deliver your goods within 3-5 working days in stock, without stock 7-10 working days after an order confirmed
What kind of packaging you offer?
We will pack the goods well with exporting packages and bubble wrap to make sure all goods in a good condition during storage and delivery.
What kind of transportation methods you offer?
A. We usually use express delivery like DHL, UPS, FedEx, TNT and EMS, as we enjoy perfect discount in these companies.
B. We also can deliver your goods by air and sea as your request.
