Specifications
1.7035/41cr4/40cr/5140 machinning surface:1.Dia:20-600mm*length:2-12m or customize
2.UT up to standard SEP 1921-84 Class C/c
5140 machinning surface
1.Grade: 5140 /1.7035/40Cr/41Cr4
2.Size: Dia: 12-600mm, Length: 2000mm-12000mm
3.Delivery condition: Hot forged +Rough machined (black surface after Q/T)+ Turned (optional)
4.Technical Data: According to the customer's requirement of Chemical Composition, Physical Properties and Mechanical Testing
5.Test: ultrasonic test according to SEP 1921-84 C/c)
Comparable Standards:
| AISI/SAE | DIN | W.Nr. | AFNOR | JIS | BS | SIAU | GB,YB |
5140 |
41Cr4 | 1.7035 | - | SCr440 | - | - | 40Cr |
Chemical Analysis (%):
| C | Mn | Si | Cr | Ni | Mo | P | S |
| 0.38-0.45 | 0.60-0.90 | 0.40 | 0.90-1.20 | - | - | ≤0.035 | ≤0.035 |
6.Application:
Mainly used for making various kinds of machinery,automobile,mining spare part.
7. Ready stock: diameter 20/22/25/26/28/32/35/38/42/45/50/55/60/65/70/75/85/90/95/
100/110/120/130/140/150/160/170/180/190/200/210/200/230/240/250/260/270/280/290/300/400/500mm
8.origin: Guangdong, China
