H264 Dvr Camera Car Dvr DVR5216A Poe DVR5204A Rearview Mirror Manual Car DVR5208A Mobile Dvr hd Dvr Manual Car Dvr TOP
Negotiable
MOQ: 5 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
DAHUA or OEM
Model Number:
DVR5204A/DVR5208A/DVR5216A
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Dahua DVR5116H hd Sdi Firmware Dvr DVR5108H DVR5104H Manual Car Camera Kit 3g Mobile Dvr Poe Hikvision Dvr TOPNegotiableMOQ: 5 Pieces -
TOP Manual Car Camera Kit DVR5104H Dahua DVR5116H Hikvision Dvr hd Sdi DVR5108H Firmware Dvr 3g Mobile DvrNegotiableMOQ: 5 Pieces
-
TOP DVR5808/DVR5816 Dahua H264 HD Sdi Dvr Firmware Dvr Manual Poe Car Dvr Kit HD DVR5804 Hikvision Dvr ZOOM 3g Mobile DvrNegotiableMOQ: 2 Pieces
-
TOP hd Sdi Dvr Kit 3g Mobile Dvr Manual Car Camera MAX H264 Firmware hd Dvr Manual DVR5108/DVR5116HE DVR5104HE Hikvision DvrNegotiableMOQ: 5 Pieces
-
HD-AHD DVR 720P 16 Channel hd Dvr Ahd CCTV H.264 Android Gps DvrNegotiableMOQ: 1 Set
Place of Origin
Zhejiang, China
Brand Name
DAHUA or OEM
Model Number
DVR5204A/DVR5208A/DVR5216A
We sale dahua whole range of products: IP camera, NVR,DVR,encoder and decoder,IP SAN. Low price!
Contact :
h264 dvr camera car dvr DVR5216A poe DVR5204A rearview mirror manual car DVR5208A mobile dvr hd dvr manual car dvr TOP
Overview :
> Up to 4/8/16 cameras with 1080p realtime preview
> H.264 dual-stream video compression
> Full channel @D1(4CIF) realtime recording
> HDMI / VGA / TV simultaneous video output
> All channel synchronous realtime playback, GRID interface & smart search
> 3D intelligent positioning with Dahua PTZ dome camera
> Support 2 SATA HDD up to 8TB, 2 USB2.0
> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
| Model | DH-DVR5204A | DH-DVR5208A | DH-DVR5216A | |||
| System | ||||||
| Main Processor | Embedded processor | |||||
| Operating System | Embedded LINUX | |||||
| Video | ||||||
| Input | 4 channel, BNC | 8 channel, BNC | 16 channel, BNC | |||
| Standard | NTSC(525Line, 60f/s), PAL(625Line, 50f/s) | |||||
| Audio | ||||||
| Input | 4 channel, RCA | |||||
| Output | 1 channel, RCA | |||||
| Two-way Talk | 1 channel Input, 1 channel Output(reuse the audio output channel), BNC | |||||
| Display | ||||||
| Interface | 1 HDMI, 1 VGA, 1 TV, 1 Spot, BNC | |||||
| Resolution | 1920×1080, 1280×1024, 1280×720, 1024×768 | |||||
| Display Split | 1/4 | 1/4/8/9 | 1/4/8/9/16 | |||
| Privacy Masking | 4 rectangular zones (each camera) | |||||
| OSD | Camera title, Time, Video loss, Camera lock, Motion detection, Recording | |||||
| Recording | ||||||
| Video/Audio Compression | H.264 / G.711 | |||||
| Image Resolution | D1/4CIF(704×576/704×480) / HD1(352×576/352×480) / 2CIF(704×288/704×240) / CIF(352×288/352×240) / QCIF(176×144/176×120) | |||||
| Record Rate | Main Stream: | D1/HD1/2CIF/CIF(1~25/30fps) | ||||
| Extra Stream | CIF/QCIF(1~25/30fps) | |||||
| Bit Rate | 48~4096Kb/s | |||||
| Record Mode | Manual, Schedule(Regular(Continuous), MD, Alarm), Stop | |||||
| Record Interval | 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec | |||||
| Video Detection & Alarm | ||||||
| Trigger Events | Recording, PTZ, Tour, Alarm, Video Push, Email, FTP, Spot, Buzzer & Screen tips | |||||
| Video Detection | Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank | |||||
| Alarm Input | 4 channel | 8 channel | 16 channel | |||
| Relay Output | 3 channel | |||||
| Playback & Backup | ||||||
| Sync Playback | 1/4 | 1/4/9 | 1/4/9/16 | |||
| Search Mode | Time/Date, Alarm, MD & Exact search (accurate to second), Smart search | |||||
| Playback Functions | Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom | |||||
| Backup Mode | USB Device / Network | |||||
| Network | ||||||
| Ethernet | RJ-45 port (10/100M/1000M) | |||||
| Network Functions | HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, Alarm Server | |||||
| Max. User Access | 20 users | |||||
| Smart Phone | iPhone, iPad, Android, Windows Phone | |||||
| Storage | ||||||
| Internal HDD | 2 SATA ports, up to 8TB | |||||
| Auxiliary Interface | ||||||
| USB Interface | 2ports (1 Rear), USB2.0 | |||||
| RS232 | 1 port, For PC communication & Keyboard | |||||
| RS485 | 1 port, For PTZ control | |||||
| Environmental | ||||||
| Power Supply | DC12V/ 3.3A | |||||
| Power Consumption | 15W(without HDD) | |||||
| Working Environment | -10 ~+55°C / 10~90%RH / 86~106kpa | |||||
| Dimension(W×D×H) | 1U, 375mm×285mm×45mm | |||||
| Weight | 2.35KG(without HDD) | |||||
