Home > Security & Protection > Surveillance, Control & Protection > CCTV Camera > Surveillance Products

Surveillance Products

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

K&D

Model Number:

KD-HA11XD72

Contact Supplier Request Quote Chat Now

Shenzhen Guowei Security Electronic Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

FOB Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name K&D

Model Number KD-HA11XD72

Type IP Camera

Style Box Camera

Sensor CCD

Technology Other, megapixel

Specifications

surveillance products
*1/3" SONY progressive scanning CCD
*support SD card
*support mobile monitor

surveillance products

1/3' SONY Progressive Scanning CCD,

Total pixels: 1.3Megapixel

Illumination Lux: day: 0.1 Lux at F1.2; Night: 0.01 Lux at F1.2 0lux@IR cut on (optional)

Definition: Primary stream: 1280x960 1280x720, Secondary stream: 640x480,640x352

With 1 channel CVBS analog video loop output, 480TV line

KD-HA11XD72	Wired
KD-HA11XD72-W	Wireless, Supports 802.11b/g Standard, Working Frequency:2.4GHz, Maximum wireless distance :100 meters, Supports WEP,WPA,WPA2
Image Sensor	1.3 Megapixel 1/3" Sony Progressive Scanning CCD
Video Standard	Digital CCD
Video Scanning	Progressive Scanning
IR-CUT	Optional
Video Compression	H.264 Main Profile @Level 3.0 / MJPEG
Dual Stream	Support
Video Definition	Primary stream: 1280x960 1280x720 Secondary stream: 640x480,640x352
Video Frame Rate	Primary Stream:1~15ps(1280x960),1~25fps(1280x720) Secondary stream: 1~25fps
Video Bit rate	32Kbps~16Mbps
Video Output	With 1 channel CVBS analog video loop output,480TV line
Audio Compression	G.726 ,8 bits/32 bits
Audio Input	1 channel external MIC interface( internal sound pick-up)
Audio Output	1 channel linear output
Title OSD	Supports channel name, date/time, and video stream information overlay; OSD location is adjustable
SD Card Interface	Support Video and Snapshots stored ,SD2.0 SDHC standard and maximum capacity:32GB
Serial port	1 RS485 interface
Alarm Input	1-channel input, NO/NC modes adjustable
Alarm Output	1-channel output, 120VAC 1A/24VDC 1A
Network interface	Self-adaption 10/100Mbps RJ45 port
Network protocol	TCP/IP,UDP,RTP,RTSP,RTCP,HTTP,DNS,DDNS,DHCP,FTP,NTP,PPPOE,SMTP,UPNP
E-mail Alarm	Support
FTP Protocol	Support
RTSP Protocol	Support
Mobile Monitor	Support Windows Mobile, Symbian, iPhone platform smart mobile monitor
Working Temperature	-10°C - +55°C
Working Humidity	0% - 90%
Power Input	DC12V/1.0A
Power Consumption	9W(MAX)
Dimension	155x75x55mm
N.W.	0.58kg
