vandal proof IP dome camera security equipment

KD-DD50XD48

480TVL, Wired

KD-DD50XD48

600TVL, Wired

Image sensor

1/3" Sony Super HAD CCD

Illumination

0.5Lux

LENS

Build in 4-9mm varifocal lens, Vandal-proof

Video Compression

H.264 Main Profile @Level 3/MJPEG

Video Definition

PAL:352*288(CIF),704*288(2CIF),704*576(D1);

NTSC:352*240(CIF),704*240(2CIF),704*480(D1)

Video Frame Rate

PAL: 1-25frames/secondNTSC:1-30frames/second

Video Compression Bit rate

32Kbps~16Mbps

Audio Input

1channel,linear input

Audio Compression

G.726

Audio Output

1channel,RCA interface, linear output

Audio talk-back

Support Audio two-way talk

Supported Protocols

TCP, UDP, IP, HTTP, FTP, SMTP, DHCP, DNS,ARP, ICMP, POP3, NTP, IPsec, UPNP,RTP,RTCP, IPV4

System Interface

10M/100M self-adapting Ethernet port,

1 RS485 port,1 RS232 port (supports transparent protocols)

SD card supports video storage and image snapping; SD2.0 standard, maximum storage 32G

Supports smart mobile monitor that is based on  Windows Mobile, Symbian and  iPhone platforms

Alarm Input

1 channel on/off input, supporting NO(normally open) or NC(normally close) sense.

Alarm Output

1 channel on/off output,120VAC 1A/24VDC 1A

Input Power Supply

DC 12V,1A

Maximum Power

Less than 7W

Operating Temperature

-20 ~ +55°C

Operating Humidity

RH85%MAX

Dimension

11.3cm(H)*14.1cm(Φ)

Net weight

600g

Package

12pcs/carton, 16kg/carton, 510x340x270mm
