WIFI Internet IP Surveillance Dome Camera

Name: WIFI Internet IP Surveillance Dome Camera
Brand: KD/OEM
SKU: 110166013

Negotiable MOQ: 50 Units (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

KD/OEM

Model Number:

KD-DD60XD52

Shenzhen Guowei Security Electronic Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name KD/OEM

Model Number KD-DD60XD52

Type IP Camera

Style Dome Camera

Sensor CCD

Technology Other, Built-in Mic, Buzzer

Special Features Other, indoor use

Specifications

>Wired Dome Internet IP Camera Surveillance Equipment
>420/540TVL,1/3" Sony Super HAD CCD
>SD card
>Free software

1/3" SONY Super HAD CCD,

Built-in Mic, Speaker, Buzzer,

fixed Lens 6mm Wired Dome Internet Camera Surveillance Equipment

KD-DD60XD42	420TVL, Wired
KD-DD60XD52	520TVL, Wired
Image sensor	1/3" Sony Super HAD CCD
Illumination	0.5Lux
LENS	Build-in 6mm fixed lens
Video Compression	H.264 Main Profile @Level 3/MJPEG
Video Definition	PAL:352288(CIF),704288(2CIF),704576(D1); NTSC:352240(CIF),704240(2CIF),704480(D1)
Video Frame Rate	PAL: 1-25frames/secondNTSC:1-30frames/second
Video Parameters	Brightness, Hue, Contrast, Saturation, Image quality.
Streaming Format	Optional Video Streaming or Audio &Video composite Streaming
Video Compression Bit rate	32Kbps~16Mbps
Audio Input	1channel,linear input
Audio Compression	G.726
Audio Output	1channel,RCA interface, linear output
Supported Protocols	TCP, UDP, IP, HTTP, FTP, SMTP, DHCP, DNS,ARP, ICMP, POP3, NTP, IPsec, UPNP,RTP,RTCP, IPV4
System Interface	Build in, Speaker and Buzzer.
	10M/100M self-adapting Ethernet port,
	1 RS485 port (supports transparent protocols)
	SD card (maximum 32GB)
	Support RF remote controller(KD-NVC82WF)
	Supports smart mobile monitor that is based on Windows Mobile, Symbian and iPhone platforms
Alarm Input	1 channel on/off input, supporting NO(normally open) or NC(normally close) sense.
Alarm Output	1 channel on/off output,120VAC 1A/24VDC 1A
Input Power Supply	DC 12V,1A
Maximum Power	Less than 6W
Operating Temperature	-10 ~ +55°C
Operating Humidity	RH85%MAX
System Requirements	Operation System: Microsoft Windows 98/ME/2000/XP/2003 Browser: Microsoft Internet Explorer 5.x or above
Dimension	164mm * 137mm * 113mm
Net weight	560g
Package	10pcs/carton, 13kg/carton, 930x270x365 mm
