Specifications
3g IP Camera with 1 channel RS485* 1/3" SONY Super HAD II CCD
* support EVDO( CDMA2000),WCDMA
* IP IR camera
3g IP Camera with 1 channel RS485
KD-DD60RD42 |
420TVL, 0.5Lux(color)@F1.2, 0Lux(B/W)@IR on,Wired |
KD-DD60RD42-W |
420TVL, 0.5Lux(color)@F1.2, 0Lux(B/W)@IR on,Wireless Supports 802.11b/g protocol, 2.4GHZ, maximum wireless distance can be 100 meters, Supports WEP,WPA,WPA2 |
KD-DD60RD42-3G |
420TVL, 0.5Lux(color)@F1.2, 0Lux(B/W)@IR on, support 3G Network: EVDO( CDMA2000),WCDMA |
KD-DD60RD52 |
520TVL, 0.2Lux(color)@F1.2, 0Lux(B/W)@IR on,Wired |
KD-DD60RD52-W |
520TVL, 0.2Lux(color)@F1.2, 0Lux(B/W)@IR on,Wireless Supports 802.11b/g protocol, 2.4GHZ, maximum wireless distance can be 100 meters, Supports WEP,WPA,WPA2 |
KD-DD60RD52-3G |
520TVL, 0.2Lux(color)@F1.2, 0Lux(B/W)@IR on, support 3G Network: EVDO( CDMA2000),WCDMA |
Image sensor |
1/3" Sony Super HAD II CCD |
Video compression |
H.264 Main Profile @Level 3/MJPEG |
IR function |
Built- in 18 pcs IR led, IR distance: 10m |
Video Definition |
PAL:176X144(QCIF),352*288(CIF),704*288(2CIF),704*576(D1) NTSC:176X120(QCIF),352*240(CIF),704*240(2CIF),704*480(D1) |
Video Frame Rate |
PAL: 1-25fps NTSC:1-30fps |
Video Bit rate |
32Kbps~16Mbps |
Audio Compression |
G.726 , 32K bits |
Audio Output |
1channel, linear output, |
Audio Input |
1 channel external MIC interface( internal sound pick-up) |
Video Output |
With 1 channel CVBS analog video loop output |
Title OSD |
Supports channel name, date, and video stream information overlay; OSD location is adjustable |
SD Card Interface |
Support Video and Snapshots stored ,SD2.0 SDHC standard and maximum capacity:32GB |
Network Interface |
Self-adaption 10/100Mbps RJ45 port |
Network protocol |
TCP/IP,UDP,RTP,RTSP,RTCP,HTTP,DNS,DDNS,DHCP,FTP,NTP,PPPOE,SMTP,UPNP |
Serial port |
1 channel RS485 |
Alarm Input |
1channel input, NO/NC modes adjustable |
Alarm Output |
1 channel output, 120VAC 1A/24VDC 1A |
E-mail Alarm |
Support |
FTP Protocol |
Support |
RTSP Protocol |
Support |
Mobile Monitor |
Supports smart mobile monitor that is based on Windows Mobile, Symbian and iPhone platforms |
Working Temperature |
-10°C - +55°C |
Working Humidity |
0% - 90% |
Power Input |
DC12V/1.0A |
Power Consumption |
9W (MAX) |
Dimension |
164mm * 137mm * 113mm |
Net weight |
0.6kg |
Package |
10pcs/carton, 13kg/carton, 930x270x365 mm |
