Ozone Aging Test Chamber

Name: Ozone Aging Test Chamber
Brand: ASLi
SKU: 110164213

US$ 2,000 - 8,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

ASLi

Model Number:

OA Seires

Dongguan ASLi Test Instrument Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHENZHEN

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name ASLi

Model Number OA Seires

Power Other, Electronic, AC 220V

Usage Universal Testing Machine

Ozone aging test chamber application:

Ozone aging test chamber is used to test the ozone environment, the characteristics of crack-resistant rubber, ozone

resistance testing machine, can control and adjust the concentration of ozone environment, to determine the anti-ozone properties of the specimen.

Ozone aging test chamber features:

1. Stainless steel inside and outside

2. Outside made iron with powder coating

3. Durable ozone generator

4. Insulation material is High-density glass fiber cotton

5. Bottom is universal round wheel and fixed foot

6. Window materials is multilayer steel-glass, the inside is chip conductive

Ozone aging test chamber technical parameters:

Model	OA-80	OA-408	OA-800
Internal Dimensions WxHxD (mm)	400x500x400	600x850x800	1000x1000x800
Internal Dimensions WxHxD (mm)	950x1650x950	1200x1950x1350	1600x2000x1450
Temperature Range	RT+10°C~+65°C
Control Accuracy of Temperature	±0.5°C
Distribution Uniformity of Temperature	±2.0°C
Indication Resolution of temperature	0.1°C
Ozone Concentration (pphm)	1~1000, adjustable
Tolerance of Ozone Concentration	≤10%
Ozone Generator	Silent discharge tube type
Internal and External Material	Material of the inner box is SUS 304# stainless steel, of the outer box is stainless steel or SEE cold-rolled steel with paint coated.
Insulation Material	Polyurethane rigid foam / superfine glass fiber cotton
Security	Leakage, short circuit, over-current protection
Power	AC 220V
