salt spray machine
machine view
Model |
SH-60 |
SH-90 |
SH-120 |
SH-160 |
SH-200 |
||||
|
Internal Dimension WxHxD (mm) |
600x450x400 |
900x600x500 |
1200x800x500 |
1600x800x500 |
2000x1000x500 |
||||
|
External Dimension WxHxD (mm) |
1100x600x1200 |
1400x950x1200 |
1900x1300x1400 |
2300x1300x1400 |
2700x1500x1500 |
||||
Lab Temperature |
Saline test (NSS ACSS) 35±1 °C ;Corrosion Test (CASS)50±1 °C |
||||||||
Pressure Bucket Temperature |
Saline test method (NSS ACSS) 47±1 °C / Corrosion Test (CASS)63±1 °C |
||||||||
Lab Capacity(L) |
110 |
270 |
500 |
800 |
1500 |
||||
Saline Capacity(L) |
15 |
25 |
40 |
40 |
40 |
||||
Saline Concentration |
5% concentration of NaCl, or every Liter 5% NaCl add 0.26g CuCl2H2O |
||||||||
|
Compressed Air Pressure(Kgf) |
1.0~6.0 |
||||||||
Spray Volume |
1.0~2.0ml /80cm2 /h(working at least 16 hours, and take the average value) |
||||||||
Spray Form |
Continuous Spraying or Programmable Spraying |
||||||||
Power |
AC220V 1 Ph 3 lines15A |
||||||||
Weight(Kg) |
65 |
80 |
120 |
160 |
200 |
||||
salt spray machine applications:
Salt Spray Corrosion Test Chamber is specially designed for the testing of the corrosion erosion
resistance of the products after their material surfaces have been treated with electric plating,
anodizing, spray coating, anti-rusting oil and other anti-erosion treatment.
salt spray machine Features:
1. Adopt automatically or manually adding water system, can watered by itself while lack of water.
2. Precise glass spray nozzle, good uniformity, mist dropping naturally, no NaCl crystallized salt
3. Double over-heat protection devise and alarm when water short storage to ensure use safety.
4. Digitally temperature controller, PID controlled, precision of ±0.1°C
5. Laboratory direct steam-heated, even heating speed, reducing the standby time.
6. Tapered Spray tower, even mist dropping
7. Saturated bucket is SUS #304, convenient for heating and humidifying, offer humidity for testing
8. Concentration of NaCl: 5%;PH of the water:6.5-7.2 (Liquid)
ASLi main products:
Established in 1988, ASLi (China) Test Equipment Co., Ltd is specialized in manufacturing a variety of quality inspection instruments, testing equipments and other high-tech products .
Main product including:
Environmental chambers, temperature (humidity) chamber, PCT /Hast chamber (Highly accelerated stress test chamber),ESS chamber, Walk in stability chamber,Vacuum oven,Altitude chamber,vibration test system, mechanical shock tester,environmental combined vibration chamber,etc
Ms. Doris Zhou
ASLi (CHINA) TEST EQUIPMENT CO., LTD
Company Add.:Building C,JinHui Industrial Park, LiXin town,East City district 523125,DongGuan City,China
Tel.:0086-769-23164266
Fax:0086-769-22851784
Skype: asli.test
Website:
