Temperature Humidity Salt Spray Testing Machine

Name: Temperature Humidity Salt Spray Testing Machine
Brand: ASLi
SKU: 110161733

US$ 18,000 - 50,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

ASLi

Model Number:

THS-Series

Dongguan ASLi Test Instrument Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Any port of China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name ASLi

Model Number THS-Series

Power Other, Electronic, AC220V

Usage Other, corrosion test

Temperature Humidity Salt Spray Testing Machine Application:

Temperature Humidity Salt Combined Spray Test Chamber is used for imitating natural status in increase imitation test.

The imitating condition is harder than status that we usually meet. The tester can combine the follow status such as:

salt smog, dry, humidity, normal temperature, low temperature.The tester is for product used in intense changeable

environment, such as: parts of automobile, navigation equipment, camera equipment, building material, electroplate

coating and resistant to metal electrolytic corrosion in electrical system.

Temperature Humidity Salt Spray Testing Machine Features

1. Adopt Humidity and temperature Controller with LCD touch screen digital display, R232 or R485 communication

interface. (Temperature and humidity recorder, can keep complete records of the humidity and temperature graphs.

This is optional.)

2. Operation mode: programmable or constant

3 Capacity of Programmable operation is 100 groups 100 steps per group, and 100H per step

4. Capacity of constant operation is 10000H.

5. Memory function: in case of a power cut, the machine can resume the unfinished test as soon as power is recovered.

Temperature Humidity Salt Spray Testing Machine Technical Parameters:

Model	THS-900A	THS-900B
Test Standard	ACSS,SOAK,DRYAIR,HUMI,ROOMAIR	ACSS,DRYAIR,HUMI
Inner Dimension W×H×D (mm)	900×600×500	900×600×500
External Dimension W×H×D (mm)	1500×1300×1000	1500×1300×1000
Temperature Range	-10ºC ~ +80ºC	RT +10 ºC ~ +80ºC
Humidity Range	60% ~ 95%RH (Temperature RT+10ºC ~ 70ºC)	60% ~ 95%RH(50ºC ~ 70ºC)
Analytic Accuracy / Distribution Uniformity of Temperature and Humidity	0.1ºC; 0.1% R.H/±2.0ºC; ±3.0% R.H.
Control Accuracy of Temperature and Humidity	±0.5ºC; ±2.5% R.H.
Pressure Bucket Temperature	Saline test method (NSS ACSS) 47±1 ºC Corrosion Test (CASS)63±1 ºC
Compressed Air Pressure (KGf)	1.0~6.0
Spray Volume	1.0~2.0ml /80cm2 /h(working at least 16 hours, and take the average value)
Spray Method	Continuous Spray
Power	AC220V 20A	AC220V 15A
