Shenzhen Gwsecu factory outdoor 1.3 megapixel ahd mini hd ir bullet camera
Key Features
> HD resolution 1280x720P
> Minimum illumination : 0.01Lux(AGC ON), 0Lux IR on
> Video output AHD 720P /960H adjustable
> OSP antioxidant PCB, power/video dual lightning protection design
> OSD menu control up the coaxial cable (UTC)
> Day/Night (ICR), AWB, AGC, BLC, 2D/3D-DNR
> Motion Detection, Privacy Mask, Mirror
> 18pcs small IR array , IR distance 20 meters
> Fixed lens 3.6/6/8mm
> IP66
Technical Specifications
Model |
GW-HW10AC72L-AHD |
GW-HW10AC72E-AHD |
Camera | ||
Image Sensor |
1/3" 1.27 Mega pixels Sony CMOS |
1/3" 1.2 Mega pixels Aptina CMOS |
Effective Pixel |
1305(H) x 977 (V) |
1280(H) x 960(V) |
Video Resolution |
720P@25/30fps |
|
Electronic Shutter |
AUTO, 1/50(60)-1/100,000sec |
|
System |
PAL/NTSC |
|
Min. Illumination |
0.01Lux(AGC ON), 0Lux IR on |
|
Video Output |
AHD 720P/960H adjustable |
|
Day/Night |
Auto/Color/(B/W)/EXT (OSD switch) |
|
S/N Ratio |
≥72dB |
≥44dB |
White Balance |
AUTO |
|
WDR |
Digital WDR |
|
AGC/BLC |
Support |
|
DNR |
2D/3D DNR, multi-levels adjustable |
|
OSD Menu |
Multi languages OSD menu control up the coaxial cable (UTC) |
|
Language |
English/ Simplified Chinese/Traditional Chinese /German/French/ Italian/ Spanish/ Polish/ Russian/ Portuguese/ Dutch/ Turkish |
|
Other |
Defog, Motion Detection, Privacy Mask, Mirror, Flip |
|
IR Led |
18pcs IR array leds |
|
IR Distance |
20m |
|
Lens | ||
Focal length |
Fixed lens 3.6/6/8@ F2.1/F2/F2.2, M12 |
|
General | ||
Power Supply |
DC12V±10%, wide voltage 9V-18V |
|
Power Consumption |
0.72W/2.64W(IR ON) |
|
Operating Environment |
-20ºC ~ +60ºC Humidity less than95%(Non-condensing) |
|
Dimensions(mm) |
173×62×67.7mm |
|
Weight |
0.45KG |
|
AHD Introduction:
*What is AHD?
Analog High Definition
*What's AHD's features:
Coaxial transmission,super long range,convenience for users
We offer many kinds Analog HD CCTV Camera Products :
HD SDI Camera, HD CVI Camera, HD AHD Camera, 1.0MP AHD Camera, 1.3MP AHD Camera, 720P AHD Canera, 960P AHD Camera, AHD Camera ...
AHD camera can be widely used in hotel, Elevator, bank, school, home,shopping mall,office, warehouse and inside surveillance surroundings and etc.
Advantage of AHD camera:
1. High resolution: Advanced signal filtering, 3D noise reduction, higher image resolution, better image reproduction.
2. Long range transmission distance: max. 500 meters over traditional 75-3 coaxial cable.
3. No video latency: Uncompressed video, real time transmitting
4. Better compatibility: Compatible with D1/960H products.
5. Easy to install: Support OSD menu, easy to operate and install
6. Low cost: Same price like traditional analog camera, but high definition image quality.
Any further question please contact me via skype.
My skype ID is sunnylin2008,
whatsapp is +8613590351765.
E-mail: sunny(at)
We attend worldwide exhibitions in Dubai, Las Vegas, Moscow, London, Germany, Thailand, South Africa. "Honest" and "Sincerity" is the principle we serve the customers.
1. Leading and professional manufacturer in CCTV industry
2. 9 years R&D and export experience
3. High Quality(material)
4. Competitive and reasonable price
5. Fast Delivery
6. Best pre-sale, sale and after-sale service
7. 2 year warranty and lifetime maintenance
8. OEM & ODM
9. CE,FCC,RoHS,ISO9001-2008 passed
CCTV manufacturer started 2001.
GWSecu Camera Special heat-dissipate structure:
(Enabled cameras 7*24 stable performance)
