Help CenterG01-100 Welding Tip Cutting Tip Copper Welding Tips
Related Products
-
Acetylene Gas Welding Welder Brass Regulator Pressure Gauge M60/863US$ 1 - 18MOQ: 1 Set -
G01-300 Copper Propanal Oxygen Cutting Torch Oxy Acetylene Automatic Cutting TorchUS$ 40 - 80MOQ: 1 Piece
-
G03-30 Injection Torch Tip Acetylene Torch Nozzle Copper Cutting NozzleUS$ 1 - 10MOQ: 10 Pieces
-
G02-100B2 Cutting Torch Polish Flame British Type Hand Torch Oxy PropaneUS$ 10 - 60MOQ: 1 Piece
-
G01-100K Oxygen Acetylene TorchUS$ 15 - 25MOQ: 15 Pieces
- Product Name : Cutting Nozzle;Model : G01-100 1#2#3#
- Material : Copper;Color : Copper Tone, Gold Tone
- Cutting Thickness : 5-100mm;Oxyacetylene Working Pressure : 0.3-0. 5MPa
- Acetylene Working Pressure : 0.001-0.1MPa;Total Size : 17x 63mm/ 0.67" x 2.5"(D*L)
- Weight : 58g;Package Content : 1 x Cutting Nozzle
-
Order# Model# Aperture
(mm)
Cutting Thickness
(mm)
Oxygen Pressure
(Mpa)
Aletylene Pressure
(Mpa)
QTY Gross Weight
(Kg)
Net Weight
(Kg)
Volume
(Cm3)
22041L 1# 1 5-30 0.3 0.001-0.1 30 180 1.886 0.058 12×11.8×12.6 22042L 2# 1.3 30-60 0.4 0.001-0.1 30 180 1.886 0.058 12×11.8×12.6 22043L 3# 1.6 60-100 0.5 0.001-0.1 30 180 1.886 0.058 12×11.8×12.6
- Used to gas cut mild steel plate.Suitable for injection type torches for cutting.On the tip surface, there is a main cutting gas orifice in the center and a ring shaped preheat orifice.
Item will be shipped within 1 business day by Air Mail on payment received .
Arrival time (estimated):
- United States : 8-15 working days
- United Kingdom / Australia / Canada: 8-15 working days
- Germany / France / Spain / Eastern Europe: 10-25 working days
- Other countries: 25-35 working days
Delivery time depends on destination and other factors, sometimes it may take a little more time for delivery.
ChuanJun was founded by Wang Jun when he opened the first premises in Road #170, Kede Industrial Hardware Center, on the 1st August 2001 and with the effort, support and dedication of many people, he has since steered the company through its carefully managed expansion programme along to the present day.
ChuanJun is now one of the China's largest industrial supplies companies with over 200 employees in Guangxi. The company is unique in having: 4200m2 warehouse in DaHua Road, 5 Distribution Shops - an export division operating in over 50 countries - a team of "time-served" sales service team - unique inter-company delivery system enabling rapid access to products, services and information. The Company intends to extend its global coverage during the coming years and is always like to hear from interested sales partners.
ChuanJun people are totally committed to working closely with every customer and supplier, for the benefit of all. The development of products and training of people, creating the opportunities that are the foundation of our Company's success and growth - these positive contributions are part of the long term success and future security of the company and its people.
Our Prime Objective is to be...
"The Complete Industrial Supply Company"
