1. Vertical Leaf Filter Main Application:
The products are mainly used for fluid precision filtration for oil, paint, pigment, food, beverage, pharmaceutical, grease, chemical
and other industries fluid, also for filtration aid and decolourant.
Petrochemical Industry : polyether, diesel, lubricating oil, white oils, transformer oils, ozokerite, mineral oils and a variety of base oil.
Oil : crude oil, floating oil, gas oil, winter oil, stearin and other vegetable oils.
Coating : varnish and resin Paint, lacquer, dyes and so on.
Food : gelatin, sound juice, salad oil, starch, sugar, monosodium glutamate, fruit juice, milk and other types of wines and beverages.
Pharmaceuticals : hydrogen peroxide, vitamins, such as glycerol
Organic Chemicals : Various organic acids, alcohols, such as fat, benzene, formaldehyde, ether.
Other : Various additives and water treatment.
2. Vertical Leaf Filter Structure feature:
♦ Unique design of the filter plate, without Filters and filter cloth, which can reduce filtration cost dramatically.
♦ Full closed filtering operation with no pollution, no loss of material.
♦ Automatic left residue of vibration device for automated continuous operations.
♦ Automatic valve slag, which can dramatically reduce labor intensity.
3. Vertical Leaf Filter Filtration Principle:
Metal mesh + filter aid + pressure
Metal plates multi - seat type screen and frame composition.
Filter a variety of filter aid. Such as diatomaceous earth, clay, bleaching earth.
When the pressure difference, filter aid in the formation of filter cake on the screen, that is the filter.
4. Specification
Filtering area |
Barrel diameter |
Filter spacing |
Imput |
Output |
Overflow port |
Slag-drip opening |
Height |
Weight |
4 |
600 |
70 |
DN50 |
DN80 |
DN32 |
DN300 |
2100 |
480 |
6.5 |
650 |
70 |
DN50 |
DN80 |
DN32 |
DN400 |
2350 |
800 |
15 |
900 |
70 |
DN50 |
DN80 |
DN32 |
DN400 |
2450 |
1500 |
20 |
1100 |
75 |
DN50 |
DN80 |
DN32 |
DN500 |
2450 |
1800 |
25 |
1100 |
75 |
DN50 |
DN80 |
DN32 |
DN500 |
2800 |
2100 |
30 |
1200 |
75 |
DN50 |
DN80 |
DN32 |
DN600 |
2550 |
2500 |
40 |
1300 |
75 |
DN70 |
DN80 |
DN50 |
DN600 |
3400 |
3400 |
50 |
1400 |
75 |
DN80 |
DN80 |
DN50 |
DN600 |
3500 |
3800 |
60 |
1500 |
75 |
DN80 |
DN80 |
DN50 |
DN800 |
3600 |
4500 |
80 |
1600 |
80 |
DN80 |
DN80 |
DN50 |
DN800 |
3800 |
6000 |
Quality and Service Commitment:
Our company always put the interests of customers and product quality to the first place,and always
adhere to the"no best,only better" as our purpose. We will be commitment to provide high quality
products with perfect site services and aftersales service.
Now the specific commitments are as follows:
1.Ensure to timely provide complete sets of equipment and accessories.
2.Ensure that one-time installation debugging acceptance.
3.To provide high quality material with preferential price.
4.Priority to provide customer our new craftworks and products.
5.Free training technological operator to ensure the trained staff can operation independently.
6.In the installation process,we will appoint a installation supervision staff on the spot.
7.we will offer an experienced project manager, organize a good installation team for the work of
field installation debugging.
