Panorama Reverse Auxiliary System
1, This product is 360 degrees panoramic image system and overall monitoring traffic recorder perfect combination. The system installed in the front of the vehicle air through the grid, reflector and licence on the shelf after camera for real-time spectacle of capture, finally after software synthesis shown on the screen, for you sweep in the car driving, the blind area at the same time, real time records the ride of the beautiful scenery along the way.
2, Forward, backward, left, right road 4 video seamless docking, to form a picture of 360 degree panorama (also called 3 d panorama, panoramic ring view).
3, Four road record video in real time, and can refer to historical driving record. The start-up is automatically video, but according to need closed or open any video of all the way. The highest storage capacity of 32 G (conventional mode can be recorded 32 hours).
4, Installation simple. Video power wire integration. Four ways of video input control box, all the way video output (with the original car to monitor inserted can).
Product function
1, system DC12V input, camera power by the depending on the control box to provide, do not need to find another power supply, easy installation, widely used in all kinds of vehicles.
2, the car starts, the system automatically into video program. Also can default for closed.
3, the left/right lights, all depending on the system automatically shows corresponding left/right cameras and cameras before and after pictures.
4, any situation, reversing back to display screen, backing up files reset, before the cameras to switch on screen, 15 seconds to shut down.
Five, three road has triggered signals, backing up, turn left and right turn signal lines, mandatory start, response corresponding picture.
6, the all seeing reverse system, four road input to the controller, the display/DVD output all the way.
7 and have a separate depending on the control key before, can choose to display or don't show any a picture.
8, front and back, the camera around hd CMD chip, 170 degree Angle wide field of vision. Embedded installation, waterproof seismic, applicable room inside and outside work.
9, the original car cabin or have been installed after high quality depending on camera, and may, according to the actual situation of reserves.
Product parameters
The camera around before and after
1. The high resolution CMD chip
2. The resolution for the 420 lines
3. Stickup formula installation, simple and convenient.
4. Waterproof design suitable for outdoor use
5. 170 degrees wide range visible Angle
6. Light night vision function
7. Video input: 1.0 V p-p 75 Ω
8. Power: DC12V plus or minus 10% 80 mA
THE EFFECTION
1. The low power consumption by using environmental protection design
2. Video formats: PAL/TSC
3. Support around 4 road camera signal input
4. Shock and easy to carry use the design
5. 3 road mandatory start signal (reverse/turn left/right) line, mandatory start, show to should screen.
6. Video output: 1 Vp-p two road car all the way to the display/DVD, all the way DVR or not.
7. Power: DC12V, camera power by the depending on the box provided.
8. Appearance size: (long) 10 mmX (high) 6 mmX (thick) 2.6 mm
9. Net weight: about 150 grams
