Home > Electrical & Electronics > Switch > Push Button Switch > F0280 19mm LED Metal Push Button Switch Latching
F0280 19mm LED Metal Push Button Switch Latching
US$ 0.1 - 0.9
MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
OEM
Model Number:
F0280
Payment & Shipping
Payment Methods:
Port of Shipment:
ningbo shanghai shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
F0279 19mm LED Metal Push Button Switch MomentaryUS$ 0.1 - 0.9MOQ: 100 Pieces -
F0278 19mm Metal Push Button Switch LatchingUS$ 0.1 - 0.9MOQ: 100 Pieces
-
12mm Pushbutton Switch With 8 Dots, 12mm Metal Pushbutton Switch With 8 Slots, 12mm Switch With 8 SpotsUS$ 1.6 - 2MOQ: 1 Piece
-
The Connector With Wire for 25mm Metal Switch, LED Metal SwitchUS$ 0.1 - 10MOQ: 1 Piece
-
The Connector With Wire for 22mm Metal Switch, LED Metal SwitchUS$ 0.1 - 10MOQ: 1 Piece
Place of Origin
Zhejiang, China
Brand Name
OEM
Model Number
F0280
Protection Level
IP67
Max. Current
5A
Max. Voltage
250V
F0280 19mm LED metal push button switch latching
Parameter :
| Diameter: | 19mm |
| Switch Rating : | 5A/250VDC |
| Operation Type : | latching |
| The Front Shape: | Flat |
| The Crust Material: | stainless steel/Brass |
| Contact Configuration: | 1NO1NC/2NO2NC |
| IP Degree: | IP67,IK08 |
| Contact Resistance: | ≤50mΩ |
| Insulation Resistance: | ≥1000MΩ |
| Dielectric Strength: | 2000VAC |
| Operation temperature: | -20°C ~ +55°C |
| Mechanical life: | 500,000 cycles |
| Electrical life: | 50,000 cycles |
| Panel thichness: | 1~10mm |
| Torque: | 5~14Nm |
| Operation pressure: | 3~4N |
| Contact material: | Silver alloy |
| Button material: | stainless steel |
| Crust material: | stainless steel /Brass Nickel plated |
| Base: | PA66 |
| TerminalType: | pin terminal |
| LED: | dot-illuminated or ring-illuminated |
| LED color : | red,green,yellow,orange,blue,white |
