42mm High Power Hybrid Stepper Motor/ 1.8 Degree Stepping Motor 42STH34-1334A

42mm High Power Hybrid Stepper Motor/ 1.8 Degree Stepping Motor 42STH34-1334A thumbnail-1
42mm High Power Hybrid Stepper Motor/ 1.8 Degree Stepping Motor 42STH34-1334A photo-1
US$ 0.99 - 1.99 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
TEC
Model Number:
42STH34-1334A
Contact Supplier Request Quote Chat Now
Cixi Intec Import And Export Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO SHANGHAI SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name TEC
Model Number 42STH34-1334A
Phase 2
Type Hybrid
Certification CE, ROHS
Step Angle(degrees) 1.8
Holding Torque 2.2kg.cm
Current / Phase 1.33A



Product Description

42mm High Power Hybrid Stepper Motor/ 1.8 Degree Stepping Motor 42STH34-1334A  42STH34-1334A

39mm 1.8 Degree Hybrid Stepping Motor



Description:



Item Specifications
Step Angle 1.8°
Step Angle Accuracy ±5% (full step, no-load)
Resistance Accuracy ±10%
Inductance Accuracy ±20%
Temperature Rise 80 °c max (rated current 2 phase)
Operating Temperature -20 °c~50 °c
Insulation Resistance 100MΩMin.,500VDC
Electric Strength 500VAC/min
Shaft Radial Play 0.02Max. (450g load)
Shaft Axial Play 0.08Max. (450g load)
Max.  Radial Force 28N (20mm from the flange)
Max.  Axial Force 10N



 Hybrid Stepping Motor Specifications



Motor NO Rated Voltage

Current

/phase

Resistance

/phase

Inductance

/phase

 Holding Torque #of Leads Rotor Inertia Weight Detent Torque Length
Single output axle Dual output axle V A Ω mH kg.cm   g.cm2 kg g.cm mm
42STH25-0404A 42STH25-0404B  9.6  0.4   24  36  1.7 4 35   0.22  120 34
42STH34-0956A 42STH34-0956B  4  0.95  4.2  2.5  1.6  6
42STH34-0406A 42STH34-0406B  9.6  0.4  24  15  1.6  6
42STH34-0316A 42STH34-0316B  12  0.31  38.5  21  1.6  6
42STH34-1334A 42STH34-1334B  2.8  1.33  2.1  2.5  2.2  4
42STH40-1206A 42STH40-1206B  4  1.2  3.3  3.2  2.6 6 54


  0.28


  150


  40
42STH40-0806A 42STH40-0806B  6  0.8  7.5  6.7  2.6  6
42STH40-0406A
 42STH40-0406A
 12 0.4 30 30 2.6 6
42STH40-1684A
 42STH40-1684A
 2.8 1.68 1.65 3.2 3.6 4
42STH48-1206A 42STH48-1206B 4 1.2 3.3 2.8 3.17 6 68 0.35 200 48
42STH48-0806A 42STH48-0806B 6 0.8 7.5 6.3 3.17 6
42STH48-0406A 42STH48-0406B 12 0.4 30 25 3.17 6
42STH48-1684A 42STH48-1684B 2.8 1.68 1.65 2.8 4.4 4
42STH60-1206A 42STH60-1206B 7.2 1.2 6 7 6.5 6 102 0.5 280 60

42mm High Power Hybrid Stepper Motor/ 1.8 Degree Stepping Motor 42STH34-1334A42mm High Power Hybrid Stepper Motor/ 1.8 Degree Stepping Motor 42STH34-1334A



 42mm High Power Hybrid Stepper Motor/ 1.8 Degree Stepping Motor 42STH34-1334A



Main Application:

Inject printers, Analytical and Medical Instruments, Textile Equipment, Embroidery Machine, Precision Telescope Positioning Systems, High Speed Dome Camera and Robotic
