Home > Electrical & Electronics > Electric Motor > Stepper Motor > 35mm 1.8 Degree Hybrid Stepper Motor/ 35ST28-4A Stepping Motor

35mm 1.8 Degree Hybrid Stepper Motor/ 35ST28-4A Stepping Motor

US$ 0.99 - 1.99 MOQ: 10 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

TEC

Model Number:

35ST28-0504A

Contact Supplier Request Quote Chat Now

Cixi Intec Import And Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

NINGBO SHANGHAI SHENZHEN

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name TEC

Model Number 35ST28-0504A

Phase 2

Type Hybrid

Certification CE, ROHS

Step Angle(degrees) 1.8

Holding Torque 1000g.cm

Current / Phase 0.5A

Product Description

35mm 1.8 Degree Hybrid Stepper Motor / 35ST28- 0504A Stepping Motor

Description:

Item	Specifications
Step Angle	1.8°
Step Angle Accuracy	±5% (full step, no-load)
Resistance Accuracy	±10%
Inductance Accuracy	±20%
Temperature Rise	80 °c max (rated current 2 phase)
Operating Temperature	-20 °c~50 °c
Insulation Resistance	100MΩMin.,500VDC
Electric Strength	500VAC/min
Shaft Radial Play	0.02Max. (450g load)
Shaft Axial Play	0.08Max. (450g load)
Max. Radial Force	28N (20mm from the flange)
Max. Axial Force	10N

Hybrid Stepping Motor Specifications

Motor NO		Rated Voltage	Current /phase	Resistance /phase	Inductance /phase	Holding Torque	#of Leads	Rotor Inertia	Weight	Length
Single output axle	Dual output axle	V	A	Ω	mH	g.cm		g.cm²	kg	mm
35ST26-0284A	35ST26-0284B	7.4	0.28	26	27	700	4	10	0.13	26
35ST28-0504A	35ST28-0504B	10	0.5	20	14	1000	4	11	0.14	28
35ST36-1004A	35ST36-1004B	2.7	1.0	2.7	4.3	1400	4	14	0.18	36

Main Application:

Inject printers, Analytical and Medical Instruments, Textile Equipment, Embroidery Machine, Precision Telescope Positioning Systems, High Speed Dome Camera and Robotic
