Home > Electrical & Electronics > Electric Motor > Stepper Motor > 86mm High Power Hybrid Stepper Motor/1.8 Degree Stepping Motor 86STH156-6204B

86mm High Power Hybrid Stepper Motor/1.8 Degree Stepping Motor 86STH156-6204B

US$ 0.99 - 1.99 MOQ: 10 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

TEC

Model Number:

86STH156-6204B

Contact Supplier Request Quote Chat Now

Cixi Intec Import And Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

NINGBO SHANGHAI SHENZHEN

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name TEC

Model Number 86STH156-6204B

Phase 2

Type Hybrid

Certification CE, ROHS

Step Angle(degrees) 1.8

Holding Torque 120kg.cm

Current / Phase 6.2A

Product Description

High Power 86mm 1.8 Degree Hybrid Stepper Motor/Stepping Motor 86STH156-6204B

Description:

Item	Specifications
Step Angle	1.8°
Step Angle Accuracy	±5% (full step, no-load)
Resistance Accuracy	±10%
Inductance Accuracy	±20%
Temperature Rise	80 °c max (rated current 2 phase)
Operating Temperature	-20 °c~50 °c
Insulation Resistance	100MΩMin.,500VDC
Electric Strength	820VAC/min
Shaft Radial Play	0.02Max. (450g load)
Shaft Axial Play	0.08Max. (450g load)
Max. Radial Force	220N (20mm from the flange)
Max. Axial Force	60N

Hybrid Stepping Motor Specifications

Motor NO		Rated Voltage	Current /phase	Resistance /phase	Inductance /phase	Holding Torque	#of Leads	Rotor Inertia	Weight	Detent Torque	Length
Single output axle	Dual output axle	V	A	Ω	mH	kg.cm		g.cm²	kg	g.cm	mm
86STH65-5904A	86STH65-5904B	12V (customized)	5.9	0.29	1.7	34	4	1000	1.7	0.8	65
86STH65-2808A	86STH65-2808B	12V (customized)	2.8	1.4	3.9	34	8	1000	1.7	0.8	65
86STH80-5504A	86STH80-5504B	12V (customized)	5.5	0.42	3.5	45	4	1400	2.3	1.2	80
86STH80-4208A	86STH80-4208B	12V (customized)	4.2	0.8	3.5	45	8	1400	2.3	1.2	80
86STH118-6004A	86STH118-6004B	12V (customized)	6	0.5	6	85	4	2700	3.8	2.4	118
86STH118-4208A	86STH118-4208B	12V (customized)	4.2	1.2	6.5	85	8	2700	3.8	2.4	118
86STH156-6204A	86STH156-6204B	12V (customized)	6.2	0.8	9	120	4	4000	5.3	3.6	156
86STH156-4208A	86STH156-4208B	12V (customized)	4.2	1.46	8.68	120	8	4000	5.3	3.6	156

Main Application:

Inject printers, Analytical and Medical Instruments, Textile Equipment, Embroidery Machine, Precision Telescope Positioning Systems, High Speed Dome Camera and Robotic

Packaging

Company Information

As a professional electronic components manufacturer, we have more than ten years production & service experience. In order to speed up customers development, we builded long terms firm cooperation with over 500 suitable & competitive manufacturer which are from Wenzhou, Dongguan, Shenzhen, Kunshan and so on, strict QC and effective communications is our daily duty; and which bring in stable goods supply and excellent services for our customers. We run the Quality Management systerms according to the ISO9001 also certificated by RoHS, SGS, UL, CE,etc.

Over the past ten years, INTEC has built a global sales network, and established long-term strategic partnership with clients in USA, European, South Africa, Pakistan, Ski Lanka, Malaysia, etc. Constantly seeking new opportunitied to partner with organizations that are looking to expand into new markets. These companies appreciate the advantages of partnering with INTEC.

If you are interested in any of our products, please feel free to visit our website or contact us directly for more information. We also welcome any customer design (OEM & ODM) or sample.

We look forward you!

Company website: http://preview.china.cn/index.htm
Company name: Cixi Intec Import And Export Co., Ltd.
Company address: No. 202-206, Dafa Rd., Hushan, Cixi, Ningbo, Zhejiang, China (Mainland)
Telephone: 0086-574-63023977

Certifications

FAQ

Q1:How to guarantee the Quality of Industrial Parts?

A1: We have the integrated system for industrial parts quality control. We have IQC (incoming quality control), IPQCS (in process quality control section), FQC (final quality control) and OQC (out-going quality control) to control each process of industrial parts prodution.

Q2:What's the Advantage of Your Parts for Industry Products?

A2:The advantage of our products is the competitive prices, fast delivery and high quality. Our employees are responsible-oriented, friendly-oriented,and dilient-oriented. Our products are featured by strict tolerance, smooth finish and long service time

Q3:what are our machining equipmengts?

A3:Our machining equipments include CNC milling machines, CNC turning machines, stamping machines,hobbing machines, automatic lathe machines, tapping machines, grinding machines, screw machines, cutting machines and so on.

Q4:How Long is the Delivery for Your Industrial Part?

A4:Generally speaking, it will take us 15 working days for machining parts and 25 working days for stamping parts products. But we will shorten our lead time as soon as possible according to customers' demands.
