Help CenterFunctional Coating Photosensitive Anti Plating Ink for Plastic
Related Products
-
Photosensitive Anti Plate Coating for Plating Label Factories,surface UP Corrosion FactoriesNegotiableMOQ: 25 Kilograms -
3880-05 Photosensitive Anti Plate Printing InkNegotiableMOQ: 25 Kilograms
-
3880-01 Air Dry Photosensitive Anti Etching Coating for Etching ProtectionNegotiableMOQ: 25 Kilograms
-
Acid Resistant, Anti Etching Photosensitive Emulsion for MeshNegotiableMOQ: 25 Kilograms
-
Well Adhesive Coating Photosensitive Alkali Etching Resistant Ink for Electronics Aluminum ProductsNegotiableMOQ: 25 Kilograms
Specifications
strong adhesion;high resolution;strong anti-plating ability;without removing the ink when transfer to the plating machine Vitayon Chemical Industry Co.,Ltd.
Free Tel: 400-0388-848
Tel: 0086-755-84805531 Fax: 0086-755-84807508
Web:
Add: No.214, Ainan Road, Nalian, Longgang Town, Longgang District, Shenzhen,
Guangdong Province, China.
This anti plating ink offers a short time protection for all kinds of metal while doing plating(Protect the part does not need to be plated). It will be stripped after doing all the processing in the end.
Product Description
Technology character:
Item |
Normal standard |
Viscosity |
120-150(25°C,pas) |
Finess |
≤8um |
Exposure power |
6-8power(21power exposure ruler) |
Hardness |
(mitsubishi pencil,700g)≥H |
Adhesion |
(3M middle and high adhesive tape)100/100 |
Stripping |
8-10%NaOH 80-90degree,3-5min |
Operation data:
1, Pre-treatment: clean up the surface of material, remove the oil and wax
2, Opening: stir the ink evenly before using, stew it for 5-10min, during the processing, you can add our dedicated dilution to adjust the viscosity(1:0.7); if you use other dilution, please do some match test, the maximum can not be over 1 time.
3, Spraying: the thickness of ink film should be 25±5um after drying;
4, Pre-bake: use hot wind to dry it circularly for 20±5min with 80°C-90°C
5, exposure: 6-8 power(21 power exposure ruler)
6, Developing: wash it with 0.8%-1.2% Na2CO3 solvant, the pressure should be 2KG/ cm² and temperature should be 30°C±2;
7, Post bake: 150°C/30min;
8, Plating;
9, Stripping: put the material with ink into the ultrasonic cleaner with 8-10% NaOH and 80-90 degree for 3-5min.
Announcement:
1, Warranty: put the ink into a dry and dark room below 25°C, seal it well and it can keep for half a year, sunshine and light are not allowed.
2, This ink can be used as original ink, if you want to adjust the viscosity, please use dedicated
dilution, stir it for 3-5min before using, then stew it for 10min.
3. Please clean up the surface of basic material before using the ink, otherwise, it will influent the
adhesion of ink.
Remark: For more operation details, welcome to contact our company.
Quality Guarantee
1, We are a famous manufacturer in this field in China, we have our own research and development group.
Most of the products are made and named by ourselves in the market.
2, We are able to manufacture the printing ink according to customer's requirement.
3, The warranty is 6 months.
4, We use high quality materials in order to make the effect perfect. Without any impurity.
5, We have our own brand and patent. Our expert group will teach you how to use our ink. We have complete
after-service group. Any question or requirement, we will reply you in 24hours.
Pictures for your reference
Factory:
Manufacturing:
Warehouse:
Office:
Exhibition:
Shipping terms
Express: DHL, TNT, FedEx, UPs
By Sea
By aire cargo
Payment terms
T/T, Western Union, Cash
