Help CenterAuto Tool Change CNC Router G1325ATC
Related Products
Specifications
1. Taiwan LNC control system2. Japan servo motors and inverters,
3. HSD Spindle
4. CE certificate
5 AUTO tool change
CNC Auto tool change router G1325ATC
Standard Features:
1. Normal type Thick Whole Steel structure,
2. Taiwan Hiwin imported square orbits,
3. Germany ballscrew for z axis,
4. gear-wheel for x and y axises,
5. Taiwan LNC control system / TAIWAN Syntec control system / Original NC Studio control system
6. UCANCAM software( orignal version) and ARTCAM Software (copy version),
7. China domestic made 6Kw water cooled spindle / 9Kw HSD Italy air cooled spindle,
8. vacuum table,
9. water cooled vacuum pump,
10. dust extraction system with 6 zones separately control zones,
11. dust extraction hood,
12. Dust collector
13. Auto tool aligning system, Auto oiling,8 Tools changer,
14. Japan servo motors and inverters, Taiwan Delta frequency inverter,
15. 12 cutters (φ6, φ12.7),
16. 3 collets
17. Z axis tool censor
Technical Parameter:
Working area: |
1300x2500x200mm |
Spindle type: |
water cooled spindle |
Spindle power |
6 kw or 9 kw |
Spindle rotating speed |
0-24000rpm |
Power (except spindle power): |
8.87KW (include powers of: motors, drivers, inverters and so on) |
Power supply: |
AC380±10, 50 HZ |
Max moving speed: |
35m/min |
Max. working speed: |
25m/min |
Worktable: |
Vacuum table (optional: T slot table or T slot table +vacuum table) |
Locating precision: |
<0.01mm |
Min shaping character: |
Character:3x3mm,letter:2x2mm |
Operating temperature: |
5°C-40°C |
Working humidity |
30%-75%(without condensed water) |
Working precision: |
±0.05mm |
System resolution: |
±0.001mm |
Control configuration: |
DSP5.0 |
Data transfer interface: |
USB(offline) |
System environment: |
WINDOWS 2000/WINDOWS XP/ windows 7 |
Spindle cooling way: |
Water cooling by water pump (optional: chiller) |
Graphic format supported: |
G code: *.u00, * mmg, * plt, *.nc |
Compatible software |
ARTCAM, UCANCAM and other CAD or CAM softwares…. |
Cutting thickness: |
0-70mm also (depends on different material) |
Z tool censor: |
yes |
Whole machine dimension: |
3650x2050x1900(mm) |
Net weight: |
1600kgs |
Gross weight |
1650kgs |
packing |
Plywood case (veneer wood case for export) |
Machine pictures:
LNC Control system:
Original NC studio control system (specifically for auto tool change machine):
Table and square orbits:
servo motor and drivers:
Linear auto tool change:
Samples:
If you want to see other materials samples, please feel free to contact me, we shall be more than pleased to supply them.
Shipping terms:
1. By sea,
2. By air express: such as TNT, DHL, EMS, FedEx and so on. around 5days to reach.
Payment terms:
1. T/T(Telegraphic transfer)
2. L/C at sight
3. ESCROW
4. Western Union
5. If you choose shipping by sea, pay 50% in advance, the balance against copy of B/L.
If you choose shipping by air, pay 100% in advance.
Advantage:
1.Competitive prices
2.Good reputation, Attentive service.
3.Excellent quality
4. Fast delivery
