Specifications
1. table move type2. DSP control system,
3. Stone cnc router
4. CE certificate
Stone working router G6060S
Main Standard Features:
1. Normal type Whole cast iron stucture
2. Taiwan Hiwin imported three axies round orbits
3. Germany ballscrew
4. U flash disk interface DSP control system,
5. UCANCAM Software (original version) and ARTCAM Software (copy version),
6. 3 KW (imported bearing) water cooled spindle,
7. fully shielded, uneasy distorted cable,
8. 20 cutters(φ3.175, φ4, φ6), 3 collets
9. three axies dust proof, water proof,
Technical Parameter:
Working area: |
600*600*180 mm |
Spindle type: |
Water cooled spindle |
Spindle power |
3 kw |
Spindle rotating speed |
0-24000rpm |
Power (except spindle power): |
3.3 KW (include powers of: motors, drivers, inverters and so on) |
Power supply: |
AC220±10, 50 HZ |
Max moving speed: |
12m/min |
Max. working speed: |
8m/min |
Worktable: |
(optional: T slot table or T slot table +vacuum table) |
Locating precision: |
<0.01mm |
Min shaping character: |
Character:3x3mm,letter:2x2mm |
Operating temperature: |
5°C-40°C |
Working humidity |
30%-75%(without condensed water) |
Working precision: |
±0.05mm |
System resolution: |
±0.001mm |
Control configuration: |
DSP5.0 |
Data transfer interface: |
USB(offline) |
System environment: |
WINDOWS 2000/WINDOWS XP/ windows 7 |
Spindle cooling way: |
Water cooling by water pump (optional: chiller) |
Graphic format supported: |
G code: *.u00, * mmg, * plt, *.nc |
Compatible software |
ARTCAM, UCANCAM and other CAD or CAM softwares…. |
Cutting thickness: |
0-70mm also (depends on different material) |
Z tool censor: |
yes |
Whole machine dimension: |
1400*1080*1300(mm) |
Net weight: |
500kgs |
Gross weight |
650kgs |
packing |
Plywood case (veneer wood case for export) |
Samples and industries application:
Metal engraving
PCB circuit board working
Our machine photos:
Packaging: Standard export wooden case
Shipping: By sea.
1. Quality warranty:
1) The whole machine is 14 months guarantee period.
2) Technical service is whole life time of the machine.
2. After service:
1) To reply your question or solve problem: within 24 hours, whatever online via chatting tools like:
MSN, YAHOO MESSENGER, SKYPE etc, by email or by telephone.
2) Machine will offer installation video, operation video, manual.
3. Delivery time:
10-15 days after getting prepayment, usually 7-10days.
4. Payment term:
T/T 50% in advance, the balance against copy of bill of lading.
5. Document supply:
Commercial invoice ,Packing list ,Bill of lading (If other documents required , please inform us )
6. The port of shipment:
Tianjin port is available .(If other port required, please inform us)
