G3036 mini Router machine
Structure advantage:
This mini cnc what we designed with strong body, portable type, convenient for small art, gift, sign logo,
home hobby works.
Materials application:
The materials which it can do are wood, arylic, pvc, metal, stone, etc. it goes with a rotary clamp which used for
cylinder materials processing, like wood and stone cups, furniture legs etc.
Difference with other CNC router or why choose this type:
The different features of this machine with other mini CNC router is it is professional on metal and stone
working except other materials.
Machine main features:
- working size: 300x360mm
- Whole cast iron structure
- Original DSP control system
- Table move type
- Taiwan HIWIN orbits
- Standard export package (veneer wood case)
- 1.5KW water cooled constant power spindle, 24000rpm
- oil mist cooling system
Technical parameters:
Specifications |
Parameters |
X,Y,Z axis moving precision |
±0.01/300mm |
X,Y,Z axis repositioning accuracy |
±0.01mm |
X,Y,Z axis motion sensitivity |
≤0.01mm |
Working platform degrees |
≤0.02mm |
X,Y axis working area |
300*360mm |
Table size |
300*360mm |
Spindle |
1.5kw water cooled spindle |
Z axis working area |
50mm |
Max. working load |
100kgs |
Machine weight |
130kgs |
Main axle rotating speed (variator) |
0-24000rpm |
Max. Moving speed |
10m/min |
Max. Working speed |
6m/min |
Power supply |
220v single phase |
Air delivery package size |
800x800x800mm |
Sea delivery package size |
800x850x800mm |
Optional |
Rotary clamp |
.
Quality warranty:
1.The whole machine is 1 year guarantee period.
2.Technical service is whole life time of the machine
After service:
1. To reply your question or solve problem: within 24 hours, whatever online via chatting tools like:
MSN, YAHOO MESSENGER, SKYPE etc, by email or by telephone.
2. Machine will offer installation video, operation video, manual.
Samples and industries application:
Adversting signs or logs
Wood applications and furniture making
