ISO9000 Electron Tube GU23A Electron Tube
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Liaoning, China
Brand Name:
HUAGUANG
Model Number:
GU23A
Payment & Shipping
Payment Methods:
Port of Shipment:
Daian port CHINA
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
ISO9001 Electron Tube Triode FU-23S Power TubesNegotiableMOQ: 1 Piece -
100KW Electron Tube Triode FD-911S High Power TriodeNegotiableMOQ: 1 Piece
-
Electron Tube FU-431S Vacuum Tube FU-431S Electronic FU-431SNegotiableMOQ: 1 Piece
-
200KW Electron Tube FD-934S High Power Tubes Electron TubeNegotiableMOQ: 1 Piece
-
Electron Tube ISO9000 Transmitting Triode Tube FD-934S _Vacuum Tube FD-934SNegotiableMOQ: 1 Piece
Place of Origin
Liaoning, China
Brand Name
HUAGUANG
Model Number
GU23A
Type
Triode Transistor
Package Type
Surface Mount
Specifications
1.ISO9001:2008&CE2.Oscillating tube
3.Meatl-glass triode
4.Soviet technology
5.High frequence triode
GU23A power tubes
Electrical parameters
Filament voltage: 12V
Filament current: 210A
The maximum instantaneous filament current: 315A
Magnification factor: 52
Transconductance: 45mA / V
Electrode capacitance:
Anode - the gate: 65pF
Cathode - the gate: 100pF
Anode - cathode: 2 pF
Mechanical properties:
Quality: (Approx.) 11Kg (S) 14Kg (Z)
Installation: vertical, anode down
Cooling mode: water-cooled air-cooled combination of (S)
Steamed cold cold combination of (Z)
Water-cooled anode flow: ≥ 120L/min
Glass bulb air-cooled flow: ≥ 2m3/min
Air-cooled core column flow: S: ≥ 1.7m3/min
Z: ≥ 3.2m3/min
Filament leads Chuck water-cooled flow: ≥ 2.5L3/min
The gridleads to the loop water-cooling flow: ≥ 2.5L3/min
Shell and Tube highest temperature: 150 °C
Terminal maximum temperature: 100 °C
Sealing at the highest temperature: 150 °C
Maximum ratings
The maximum anode DC voltage: 12KV
Maximum anode DC current: 13A
Maximum gridDC current: 3A
Maximum anode dissipation power: 60KW
Maximum griddissipation power: 2.6KW
In typical operation: class C telegraph
Filament voltage: 12V
Anode DC voltage: 11KV
GridDC bias voltage:-500V
Anode DC current: 11.86A
GridDC current: 2.99A
Anode output power: 100KW
