PUXING Amateur Dual Band Business Radio PX-UV973

PUXING Amateur Dual Band Business Radio PX-UV973 thumbnail-1
PUXING Amateur Dual Band Business Radio PX-UV973 thumbnail-2
PUXING Amateur Dual Band Business Radio PX-UV973 photo-1
PUXING Amateur Dual Band Business Radio PX-UV973 photo-2
Negotiable MOQ: 2 Sets (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
PUXING/OEM
Model Number:
PX-UV973 UV dual band radio
Contact Supplier Request Quote Chat Now
Xiamen Puxing Electronics Science & Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Xiamen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Fujian, China
Brand Name PUXING/OEM
Model Number PX-UV973 UV dual band radio
Type Handheld
Dimensions 100mm*55mm*32mm
Frequency Range 136-174,400-470
Storage Channel 128 channels
Talk Range 5-10km

PUXING Amateur dual band business radio PX-UV973PUXING Amateur dual band business radio PX-UV973

Thanks for your appreciation to Puxing brand radios!
We design and make radios as world famous brand company, offer radios and got honorary title of “superior supplier" from them, so our product quality is reliable and price is competitive. It is helpful for you to buy; we will support our agents and distributors all the way.
PX-UV973 Professional FM transceiver is a powerful amateur two way radio.It can realize U/V cross band duplex repeater function,really dual band receive at the same time.we can adjust the A/B channel volume seperately,provide the customdesigned optimization effect for two way radio amateur.
General
Frequency Range  Dual band VHF:136-174MHz & UHF:400-470MHz
Channel Capacity 128 channels
Channel Spacing 25KHz(Wide Band) 20KHz(Middle Band) 12.5KHz(Narrow band)
Phase-locked Step 5KHz,6.25KHz
Operating Voltage 7.4 V  DC
Battery Life 1200mAh (More than 12 Hours),
Frequency Stability ±2.5ppm
Operating Temperature -20°C +55°C
Size 100mm×55mm×32mm (not including antenna)
Weight 220g (with battery, antenna)
Transmitter (ETSI EN 300 086 standard testing )
Frequency Stability ±2.5ppm
Output Power VHF5W/UHF4W
Modulation Limiting ±2.5KHz
Audio Distortion ≤3%
Audio Response +1dB~-3dB
Adjacent Channel Power ≥70dB/60dB
Spurious Radiation ≤7.5uW
Occupied Bandwidth ≤16KHz
Receiver (ETSI EN 300 086 standard testing )
RF Sensitivity ≤0.25μV
Audio distortion ≤3%
Audio Response +1~-3dB
Adjacent Channel Selectivity ≥60dB
Intermodulation Rejection ≥70dB
Spurious Rejection ≥70dB
Blocking ≥80dB
Hum & Noise -45dB
Audio output 500mW
OEM/ODM support imprint your logo on products
Warranty 1year for radio,6monthes for battery
shipment FedEx/DHL/UPS 3-5days EMS/TNT 5-8days Hon Kong Post Air Parcel takes 7-30days
note the goods will be marked “gift” or “sample” for easy customs clearance and less charge,if you need to declare the good as other item name, or specify and value for custom, pls note in order.







 PUXING Amateur dual band business radio PX-UV973PUXING Amateur dual band business radio PX-UV973
