Two Way Radio PX-328 FM Transceiver

Name: Two Way Radio PX-328 FM Transceiver
Brand: PUXING/OEM
SKU: 109991653
Availability: InStock

Negotiable MOQ: 2 Sets (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Fujian, China

Brand Name:

PUXING/OEM

Model Number:

PX-328

Xiamen Puxing Electronics Science & Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Xiamen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Fujian, China

Brand Name PUXING/OEM

Model Number PX-328

Type Handheld

Dimensions 100X55X32MM

Frequency Range 136-174/245-246/400-470/465-520MHz

Storage Channel 128 channels

Talk Range 5-10km

TOP selling radio PX-328
Compact size	100X55X32MM
Frequency Range	136-174/245-246/400-470/465-520MHz
channels	128channels
Output Power	VHF5W/UHF 4W
Battery capacity	1200-1600mAh
Weight	220g(Including battery)
Operate Mode	Simplex or Semi-duplex
Antenna Impedance	50 Ω
Operating Voltage	-20℃~+50℃
Features and functions	Battery low power alert/battery save/Busy channel lockout/All keys lock/PTT lock /three backlight display
	frequency input by keypad/power adjust by software/Memory Channel(MR) and frequency(VFO) mode switchable
	built-in FM radio receiver
	VOX/VOX delay time/VOX sensitivity level adjustable
	Channel bank store
	Real-time DC voltage display
	Open message edit/password protection
	Alpha-Numeric channel name
	Repeater offset
	End roger
	Scan modes selectable(TO/CO)
	Side tone eliminated (STE)
	TX inhibit capability
	Part reset/All reset/Factory default reset
	Time out timer
TRANSMITTER
channel spacing	Wide 25khz and Narrow 12.5khz band
Frequency Stability	±2.5PPM
Max Frequency Deviation	≤5KHz/2.5KHZ
Audio Distortion	≤3%
Modulation Character	+3dB~-3dB
Adjacent Channel Power	≥65dB/60dB
Spurious Radiation	≤7.5uW
Occupied Bandwidth	≤16KHz
RECEIVER
RF Sensitivity	<0.2uV
Audio Distortion	≤3%
Audio Response	+2dB~-10dB
Co-Channel Rejection	≥-8dB
Adjacent Channel Selectivity	≥60dB
Intermodulation Rejection	≥65dB
Spurious Response	≥70dB
Blocking	≥80dB
OEM/ODM	support imprint your logo on products
Warranty	1year for radio,6monthes for battery
shipment	FedEx/DHL/UPS/EMS/TNT
