YDH-DT-18C mobile cantilever Bridge pendant (Apart Dry and Wet)
The mobile cantilever Bridge pendant is a bridge hanging style specially designed for ICU sick rooms, observing rooms and recovering rooms. All kinds of terminals such as for medical gas, electricity, network are all gathered on the control board. The function of moving freely makes the operation more convenient. Light is equipped in the middle of the bridge , also we can equip communication machine , monitor , view telephone, background music, teaching and long-distance consultation system according to your needs.
Briege pendant Feature:
1.The cross beam and control cabinet of the tower crane adopt the imported high-strength aluminum alloy of patent technology for the one-off extrusion molding, and the surface undergoes the primary oxidation treatment
2.The tray surface is non-slip .
3.Mechanical friction damping brake.
4.Horizontal movement can accurately position without excursion.
5.The gas pipeline, power supply and computer communication line are separately arranged without interference.
6.The imported standard gas terminal(Over 20,000 of inserting and pulling out) is adopted.
7.Dry and wet areas adopt the independent design , and equip with the gas cabinet body
The horizontal translation in dry and wet areas meets requirements of omnibearing nursing.
YDH-DT-18C mobile cantilever Bridge pendant (Apart Dry and Wet) | |||
Working power |
AC220V 50Hz |
Input power: 6KVA |
|
Bridge length |
2500-3200mm |
||
Qty of light in front of bridge:2 pcs |
The back of bridge is equipped with total brake power and gas valve |
||
Dry area | |||
Shift motion (left and right ): 200-500mm |
Horizontal rotating angle:340° |
||
Qty of tray |
Three layers |
High adjusted |
|
Gas terminal interface |
Oxygen* 1 ,vacuum*1, air *1 Different color and shape, to avoid mistake |
Adopt secondary seal
|
|
sockets |
6 pcs(220V/10A) |
||
Grounding points |
2 pcs |
||
Network interface |
1 pc RJ45 |
||
Drawer: 1 pc |
Brake |
|
|
Stainless steel Injection rack unit :1 set |
Net weight:›300KG |
Loading weight:50KG |
|
Wet area | |||
Shift motion (left and right ): 200-500mm |
Arm rotate 340° |
||
Qty of tray |
One layers |
High adjusted |
|
Gas terminal interface |
Oxygen* 1 ,vacuum*1, air *1
|
Over 20,000 of inserting and pulling out |
|
sockets |
8 pcs(220V/10A) |
||
Grounding points |
2 pcs |
||
Stainless steel Injection rack unit :1 set |
Drawer: 1 pc |
Storage box:1 pc |
|
Net weight:<150KG |
Instrument loading weight:20KG |
||
Finishing: aluminum alloy one-off extrusion molding |
Install as suspended ceiling |
Accept customized |
|
Vacuum pump Station system with tank and controller
Other medical gas engineering equipment, we can supply:
Bedhead unit
air compressor
About us~
1>Our facotry specilized in Medical Pendant ,Which mainly used in the Hospital Operating Theatres (OT), or Intensive Care Units (ICU). They are ceiling mounted, Including Medical Gas Outlets, Electric Sockets, Communicate Ports, with shelves and drawer etc.
customized logo available:
made of high strength aluminum alloy
electric socket type and quantity customized
network and data interface, quantity can be customized too
2>We also supply the different standards for the gas outlets.Like German/French/British/American or other universal standards.
3>We also supply the other medical instrument for hospital,Like the staineless steel cabinet,Scrub sink station,Automatic Gas pipeline manifold system,medical pass box,Medical air compressor system and vacuum pump system,Ceiling infustion system,ceiling hospital curtain and so on.
4>All parts are produced by our own facotry.All the access are under our professional and strict controlling before out of facotry.
Good package for export, first packed by bubble film first, and then put ceiling pendant into wooden export case
wooden package for bridge pendant:
bridge pendant factory shows:
