AV-2000B1 Ventilator Portable Type
AV-2000B1 is a multi-functional ventilator, it is is applicable for children and adults in sickroom, ICU or for emergency.
Nine gear temperature control system with heating protection function.
Portable, suitable for vehicle use
Ventilator Specifications:
Display |
colored LCD, touch screen setting, big font display, free changeable angles of views |
Various ventilation modes |
SIPPV,SIMV,PCV,SPONT,MANUAL,CPAP |
Ventilation parameters |
PEEP,SIGH,IRV,Inspiratory platform |
Tidal Volume |
50-1500 mL |
Rate |
1~99bpm |
SIMVrate |
2~20bpm |
I:E |
4:1~1:8 |
Trigger sensitivity |
-1.0~1.0kPa |
PEEP |
0~25cmH2O |
Pressure control |
3~50cmH2O |
SIGH |
1.5 times the inspiratory time (60 ~ 120 times adjustable) |
Inspiratory platform |
0~50% |
Oxygen concentration |
48%~100% |
Pressure limit |
5~60cmH2O |
Parameters for ventilation monitoring |
tidal volume, ventilation volume, IPPV rate, total respiratory rate, peak pressure of airway, pressure - time waveform, flow rate - time waveform, inspiratory trigger pressure, Inspiratory platform, Oxygen concentration, battery capacity |
Safety alarm system
Airway pressure alarm |
upper limit setting range 0.3~6.0 kPa |
lower limit setting range |
0.2~5.0 kPa |
Per-minute ventilation volume alarm |
upper limit setting range 3.0~30L/min |
lower limit setting range |
1.0~10L/min |
Vt alarm |
upper limit setting range 10~2000ml |
lower limit setting range |
0~1800 ml |
Sustained high-pressure alarm |
it will give alarm when stress have consistently been higher than 2.5 kPa |
Suffocation alarm |
it will give sound and light alarm if there is no tidal volume input for 15 seconds |
Power failure alar alarm |
|
Power |
AC 220V±10% 50Hz±1Hz UPS, Storage battery |
Battery under-voltage alarm
Power loss alarm
Intubation off alarm
1. sample available
2. with English user manual and installation guide, if installation needed, we can arrange engineer to install that
3. multi-choice to meet different hospitals requirement
4. professional service from pre-sales to after-sale
1.With 20 years production experience
2.Plastic coating processing, plastic siderails, headboard/foot board, castors all manufactured by our own company, easy to control quality and quick delivery
3.Strict raw material inspection and quality control, meet ISO9001 and 13485 quality management system
4.Product pass CE(TUV) certificate
5.Export more than 40 countries, including Australia, USA, UAE, UK, South America,, Malaysia, Philippines, Saudi Arabia etc.
6.One professional export here give you better service
