Specifications
Anesthesia Machine1.External CO2 circle absorber system
2.Small and compact unit ideal for office based anesthesia
AMJ-902CV Anesthesia Machine Integrated With Anesthesia And Ventilation
The Anesthesia Machine which is researched and produced by WANROOEMED is a movable unit integrated with anesthesia and ventilation, which could be applied to closed anesthesia, semi-closed anesthesia, and semi-open anesthesia, and be applicable to Adult / Pediatric inhalation anesthesia, oxygen supply, resuscitation and respiratory management.
Special Feature:
Ventilation Method: Closed, half-closed, half-open
Small and compact unit ideal for office based anesthesia
External CO2 circle absorber system
Ventilator(option): ATH-1, ATH-1A
Main Unit:
Tidal volume (manual mode): 20-1500 ml
Work Pressure: 0.25-0.65Mpa
Flowmeter: O: 0.1-101/min
APL valve: 0.5-6.0K
O2 flush: 25-75L/min
Vaporizer:
1 vaporizer, Enflurane, Isoflurane
Capacity: 250ml
Automatic compensation for Temperature, Flow and pressure
Concentration range:
Enflurane 0.2-5%
Isoflurane 0.2-5%
Flow Range: 0.2-10L/min for concentration> 5%
0.2-15L/min
Anesthesia Machine Main specifications:
Working pressure |
0.3~0.4Mpa |
Oxygen flow control |
0~10L/minute |
The volume of soda lime tank (CO2 absorbing tank) |
1000ml |
Flowmeter |
Mechanic anti-hypoxic device and O2/N2O(Air) interlock |
O2 Flush |
25~75L/min. |
Gas supply |
O2 or O2+ N2O or O2+ Air |
Gas Supply pressure: |
O2: 0.25~0.65Mpa N2O(Air): 0.25~0.65Mpa |
Physical specification |
Packing size: 78.6 x 28.1 x 43.7 cm |
Environments |
Environment Temperature: -9~+35°C Relative humidity limits: 20%~60% Atmosphere pressure: 700~1060hPa |
Anesthesia Machine Drawings:
1. sample available
2. with English user manual and installation guide, if installation needed, we can arrange engineer to install that
3. multi-choice to meet different hospitals requirement
4. professional service from pre-sales to after-sale
1.With 20 years production experience
2.Plastic coating processing, plastic siderails, headboard/foot board, castors all manufactured by our own company, easy to control quality and quick delivery
3.Strict raw material inspection and quality control, meet ISO9001 and 13485 quality management system
4.Product pass CE(TUV) certificate
5.Export more than 40 countries, including Australia, USA, UAE, UK, South America,, Malaysia, Philippines, Saudi Arabia etc.
6.One professional export here give you better service
