Item: Unimaginable simulator game machine home theater chairs 5d cinema,5d movie,and 5d theater
online service:
Skype: ivy.huang90
TradeManager:1510385854
Mobile phone/Whats app:0086-13760836679
How 5D motion cinema work?
This cinema made of two parts, one is 3D traditional project system, as every one knows this part contain 3D movie, 3D glasses, projection screen, audio system, and projector and so on.
The other part is the simulate system, this is the most important thing, contain dynamic simulate platform, scenes simulate system and the control system.
When you are in the cinema not only you can see the 3D picture but also you can feel the movement according to movie, especially you can feel the scenes of the movie, for example, when there is a rainy scene in the movie, at the same time the audience also can feel the reality experience (raining in the cinema at the same time). 5D cinema can create several effect: Rain, snow, bubble, wind, light, leg sweep and so on.
The audiences in the cinema will be very exciting, and after the movie they will say that's so amazing. I just was in the movie!
What we can experience in the movie?
- Rain Effects - Bubble Effects
- Snow Effects - Wind Effects
- Flash Effects - Smoke/Fog Effects
- Leg Tickler - Seats Vibration
- Ear Wind - Butt Poker
- Back Poker - Water Jet
Standard Configuration
1.Projector system: Adopting double projector to realize a group image or multiple group image columnar seamless surface connection. When playing, two projectors star at the same time and corresponding to left and right movie.
2.Three-dimensional screen system: Metal Soft Screen or Hard Screen, can choose standard 4:3,16:9 screen or even circular-screen. Installing the screen frame above the ground or on the wall are available.
3.Motion seats system:5D electric platform and 5D hydraulic platform are professional design and production, in addition to the back and forth, left and right, up and down movement of tradition 3DOF platform,5D cinema platform add a lot of angles action to achieve the effect of any movement of the platform within a certain rang.
4.Special effect system: Including lighting simulation, rain simulation, snow simulation, smoke simulation, bubble simulation, hot drop dropping, vibration, air blast, mist spray, leg sticker, ear wind, ear sound and etc.
5.Computer control system: To make sure all the system can work under order, achieve good effect to the audience. Process engineers setting the order in exact time according to the movie, to control the switch of projector system, motion chair, effect machine and sound system .
Electric System Platform
| Project | Forward | Backwards | Rang of speed |
| X axis move | +183mm | -183mm | 26-261mm/s |
| Y axis move | +90mm | -300mm | 26-278mm/s |
| Z axis move | +370mm | 0 | 25-256mm/s |
| X axis move | +21° | -21° | 3-30°/s |
| Y axis move | +22° | -19° | 3-29.3°/s |
| Z axis move | +16° | -16° | 2-22.8°/s |
1.Best technology for simulation now.
2.High speed,accurate motion.
3.Almost NO maintenance.
Hydraulic System Platform
| Hydraulic base weight | 300kg |
| Maximum load weight | 2000kg |
| Voltage | 220V/380V |
| Power | 3.7KW |
| Moving coordinate | 1715mm×1400mm×550mm |
| Lifting magnitude | 210-230mm |
| Environment | indoor |
| Ambient humidity degree | lower than 70% |
| Human comfort degree | 85%-95% |
1.Standard power is 380V.(220V 240V 110V also can work with a frequency converter.)
2.The brand of motor is S.Y from Taiwan, the oil pump is EALY also from Taiwan,
we provide the best quality equipment to customer.
3. Six DOF( degree of freedom) left and right, Backwards pitching, Drop up and down.Move according to the movie.
Item:Unimaginable simulator game machine home theater chairs 5d cinema,5d movie,and 5d theater
Guangzhou Xindy Animation Technology Co.,LTD is the earliest manufacturer of 5D/7D theater equipment in China. It provided designated production, research and development in the early days. It also takes over OEM orders of dynamic seat which are very famous at home and abroad.
Sine 2008, our company has developed with independent intellectual property rights of the motor control system platform and the special effects simulation control system, we have the patent authentication of the technology, through a few years of practice testing and shop entities management, continuous technical innovation and reducing production cost, We developed dynamic cinema equipment that can be comparable to international, both in its performance and special effects animator, the price is only one over ten comparing with the foreign equipment.
why we stand out
1.We have strictly Quality Control System.
All products must be checked two processes.
First, when the hydraulic seat platform has been made, the platform will be run for 10 hours without stopping.
2. equipment must be installed and inspected to work every function before package.
There are 70movies given to you for free, and increase two movies in average for free each month in the first year.
3.The brand of motor is S. Y from Taiwan; The oil pump is ERLY also from Taiwan; The projector brand is NEC form Japanese. We offer the best equipment to customers.
4.This 5D motion seat base on hydraulic technology, We specialized in this field for 14years exactly. So the quality is very good.
5.We research, design and produce all of this equipment, so we can supply for you not only the full set of equipment but also the technology support for ever.
