Specifications
High Quality Auto Casting Label Shrink Sleeve Machine1.Round/plastic/glass
2.30-150 b/min
3.High speed servo system
4.CE
Packing Machine for High Quality Auto Casting Label Shrink Sleeve Machine
Features:
All-cover type stainless steel host machine: the whole machine is waterproof as well as rustproof.
Adjustable cutter head: unique cyclotron cut-off, double sided cutting edge with a long service life.
Single positioning centre guide pillar: more stable for label delivery.
Synchronous bottle divider: a more stable transmission for the bottle.
Bottom set label brush: more precision for casting label.
Label-controlling electric-eye shelf: unique combination of tail and electric-eye to improve the precision for cutting off the membrane materials.
Push-button control cabinet: a more humanized operation.
Independent feeding material shelf: the position of the material shelf is optional at will.
Electrical Appliance Configuration Specification
It adopts PLC programmable controller, imported servo motor, servo driver, frequency converter and transducer; also, it adopts the positioning module to ensure the casting label precise, rapid and stable.
Applicable Variety Types of Label
Various kinds of bottle types, for example: round bottle, square bottle, flat bottle, curve bottle and cup-shaped, etc.
Technical parameter
| Model | SLM-150 | SLM-250 |
| Input Power | 1.5KW | 3.0KW |
| Input Voltage | D3,380/220VAC | D3,380/220VAC |
| Production Efficiengcy | 150(Bottle/min) | 250(Bottle/min) |
| Size of Host Machine |
L2100mm x W850mm x H2000mm |
L2100mm x W850mm x H2000mm |
| Applicable Diameter of Bottle Body | D28mm-125mm | D28mm-125mm |
| Applicable Length of Lable | 30mm-250mm | 30mm-250mm |
| Applicable Thickness of Label | 0.03mm-0.13mm | 0.03mm-0.13mm |
|
Applicable Internal Diameter of Paper Tube |
(Free Adjustment) | (Free Adjustment) |
Packing Machine for High Quality Auto Casting Label Shrink Sleeve Machine
Suitable labels
Packing Machine for High Quality Auto Casting Label Shrink Sleeve Machine
Packing Machine for High Quality Auto Casting Label Shrink Sleeve Machine
What service U Tech Machine Co.,Ltd can offer you ?
• Well-trained & experienced staff are to answer all your inquiries in English and Chinese
• 24 hours for engineer response (all services part 5days in customer hand by Intl' courier).
• 2 Years guarantee
• Your business relationship with us will be confidential to any third party.
• Good after-sle service offered, please get back to us if you got any questions.
Packing Machine for High Quality Auto Casting Label Shrink Sleeve Machine
Brief Introduction
Zhangjiagang U Tech Machine Co., Ltd. is a manufacturer of bottling machine and packing with well-equipped testing facilities and strong technical force. With a wide range, good quality, reasonable prices and stylish designs, our products are extensively used in beverage and other packing machine.
Our products include: liquid bottling machines (water, fruit juice/tea, carbonated drink, oil, alcohol, machine protein drink, etc.), barreled bottling line (3-5 gallon) water treatment machines, labeling & packing machines, semi-automatic /full automatic PET bottle blowing machines, and injection molding machines, extrusion blow molding machines (PP/PE/PVC/PETG/PC...) and accessories for automation: leak tester machines, bottle bag packing machines, conveyor belts.
Our Workshop
Exhibition in Colombia
Our clients
Certification
Packing Machine for High Quality Auto Casting Label Shrink Sleeve Machine
Q1:Are you a trading company or a manufactory?
A1:We are a manufactory,can give u best service .
Q2:What’s your guarantee or the warranty of the quality if we buy your machines?
A2:We offer you high quality machines with 2 years guarantee . we will give u spare part free in 2 years
Q3:When can I get my machine after I paid?
A3:We will deliver the machines on time as the date we agreed both side.
Q4:How can I install my machine when it arrives?
A4:We will send our engineer to your side as soon as you get all your machines ready , for testing and teaching your technicians how to run the machines.
Q5:How about the spare parts?
A5:After we deal down all the things , we will offer you a spare parts list for your reference.
