Automatic Monoblock Taping Carton Packing Machine
- 10 Set / Sets per Month
- SHANGHAI
- T/T
- courrier poly mailer bags cutting and packing Machine
- automatic drink bag juice Bag Sachets Packing Machine
- automatic drink bag juice Bag Sachets Packing Machine
- Plastic Package Stick Packet Three sides Packaging Sealing Machine
- ziplock premade bag filling machine
- Friench Fries Popcorn Packaging peanuts packing machine
Product Details
Condition: | New | Application: | Beverage | Packaging Type: | Cartons |
Packaging Material: | Wood | Automatic Grade: | Automatic | Driven Type: | Electric |
Voltage: | 220/380V 50HZ | Power: | 0.4KW | Place of Origin: | Jiangsu, China |
Brand Name: | U TECH | Model Number: | FI500 Automatic Monoblock Taping Carton Packing Machine | Dimension(L*W*H): | L1700*W920*H1450MM |
Weight: | 280KG | Certification: | CE,SGS,ISO | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
Automatic Monoblock Taping Carton Packing Machine1.Imported parts
2.Pneumatic driven
3.Left&right driven belt
4.20m/m
Automatic Monoblock Taping Carton Packing Machine
Description:
Automatic Monoblock Taping Carton Packing Machine is mainly used in sealing and packing cartons, which
can be used either independently or as a necessary part of a production line.
The machine can adjust itself to different sizes of cartons. This machine adopts pneumatic method
for packaging automatically, it overcomes some disadvantages when adopts manual or semi-auto ones, such as slow speed and the unstable quality. This machine will not damage the surface
of packaged objects. The air-jar with every action point adopts AirTAC products, the capability is
very stable.
Features:
1. Sealing different sizes of cartons without adjustment by human, it will be fit automatically
2. The sealing pressure is adjustable, according to the different materials of cartons
3. The pushing strength of the movement arms on two-side can be regulated according to the weight of cartons
4. Two-side movement arms adjust the objects packaged to the right position automatically
5. The movement frame is driven by double air-jar, smart and smoothly, using long time
6. The 25kg carton can be conveyed steadily by large power convey motor
7. Pneumatic and electric parts combine perfectly, with operation convenient and simple
8. The fine structure and the harmonious color bring pleasure to both the eye and the mind.
Model | FC500 | FC500A | FC500B | FI500 |
Name | automatic carton fold&sealing machine | automatic carton fold&sealing machine | automatic carton fold&sealing machine | Full automatic carton fold&sealing machine |
Min carton dimension | L200*W120*H100 | L200*W120 *H100 | L200*W180 *H150 | L200*W165 *H140 |
Max carton dimension | L600*W500*H500 | L600*W500*H500 | L500*W400 *H400 | L600*W500 *H500 |
Sealing speed | 20m/min(10-15case) | 30m/min(20-30case) | 38m/min (35-45case) | 20m/min |
Machine dimension | L1700*W930*H1510 | L1700*W930 *H1510 | L1700*W930 *H1510 | L1700*W920 *H1450 |
Voltage | 220/380V 50HZ | 220/380V 50HZ | 220/380V 50HZ | 220/380V 50HZ |
Air consumption | 6kgf/cm3; 40nl/min | 6kgf/cm3; 40nl/min | 6kgf/cm3; 40nl/min | 6kgf/cm3; 100nl/min |
Power | 0.4kw | 0.4kw | 0.4kw | 0.4kw |
Sealing tape | W48,60,75mm | W48,60,75mm | W48,60,75mm | W48,60,75mm |
Weight | 180kg | 200kg | 280kg | 280kg |
Feature A | automatically folding | automatically folding | automatically folding with high speed | suitable for different size carton |
Feature B | manually adjust width&height | manually adjust width&height | manually adjust width&height | height and width adjustment automatically |
Feature C | sides belt driven | sides belt driven | bottom belt driven | two sides belt driven |
Automatic Monoblock Taping Carton Packing Machine
Automatic Monoblock Taping Carton Packing Machine
What service U Tech Machine Co.,Ltd can offer you ?
• Well-trained & experienced staff are to answer all your inquiries in English and Chinese
• 24 hours for engineer response (all services part 5days in customer hand by Intl' courier).
• 2 Years guarantee
• Your business relationship with us will be confidential to any third party.
• Good after-sle service offered, please get back to us if you got any questions.
Automatic Monoblock Taping Carton Packing Machine
Brief Introduction
Zhangjiagang U Tech Machine Co., Ltd. is a manufacturer of filling machine and packing with well-equipped testing facilities and strong technical force. With a wide range, good quality, reasonable prices and stylish designs, our products are extensively used in beverage and other packing equipment.
Our products include: liquid filling machines (water, fruit juice/tea, carbonated drink, oil, alcohol, plant protein drink, etc.), barreled filling line (3-5 gallon) water treatment machines, labeling & packing machines, semi-automatic /full automatic PET bottle blowing machines, and injection molding machines, extrusion blow molding machines (PP/PE/PVC/PETG/PC...) and accessories for automation: leak tester machines, bottle bag packing machines, conveyor belts.
Our Workshop
Exhibition in Colombia
Certification
Automatic Monoblock Taping Carton Packing Machine
Q1:Are you a trading company or a manufactory?
A1:We are a manufactory,can give u best service .
Q2:What’s your guarantee or the warranty of the quality if we buy your machines?
A2:We offer you high quality machines with 2 years guarantee . we will give u spare part free in 2 years
Q3:When can I get my machine after I paid?
A3:We will deliver the machines on time as the date we agreed both side.
Q4:How can I install my machine when it arrives?
A4:We will send our engineer to your side as soon as you get all your machines ready , for testing and teaching your technicians how to run the machines.
Q5:How about the spare parts?
A5:After we deal down all the things , we will offer you a spare parts list for your reference.
