Beverage,Beer,Wine Jar Flask Glass Bottle Filling Machine (3in1)
Features:
1) CE certificate
2) ISO9000: 2000 Certificate
3) Volume: 0.25-2.5L
4) PET bottle, Glass Bottle, Can Bottle
5) Automatic system
6) High efficiency, easy maintenance
Filling valves adopt high-precision mechanic filling valve with mechanism of no bottle, no vacuum zing.
Out-placement mechanic structure. There is no spring in the valve.
There are two times of vacuumizing, equipping high pressure foam simulating device.
Driving adopts combination of open-type gear and gear. Adopt stepless frequency speed adjustment.
This machine equips automatic lubrication device.
Equip automatic washing device for broken bottles.
The lift of liquid tank, capping heads and control ring is electric to adapt to different height bottles.
The product level in the filling tank is controlled by electric probe to keep stable level and reliable filling.
Adopt PLC control.
Specifications:
Model |
Washing heads |
Filling heads |
Capping heads |
Capacity(b/h) 500ml |
Motor power (KW) |
Overall dimension (mm) |
BCFG14-12-5 |
14 |
12 |
5 |
1000bph |
1.5KW |
2100x1400x2500 |
BCFG18-18-6 |
18 |
18 |
6 |
2000bph |
2.2KW |
2460x1720x2650 |
BCFG24-24-8 |
24 |
24 |
8 |
3000bph |
3KW |
3100x2100x2650 |
BCFG32-32-10 |
32 |
32 |
10 |
6000bph |
4KW |
3500x2500x2650 |
BCFG40-40-10 |
40 |
40 |
10 |
8000bph |
7.5KW |
4600x1800x2650 |
BCFG48-48-12 |
48 |
48 |
12 |
9000bph |
9.5KW |
5200x4500x3400 |
BCFG60-60-15 |
60 |
60 |
15 |
12000bph |
12KW |
6500x4500x3400 |
