TG18G HIGH SPEED CENTRIFUGE with FIXED ANGLE ROTOR
Features:
1.Microprocessor control, operated by touch panel, LED display, operated data can be saved automatically, RCF value can be set directly for working, easy to use.
2.Brushless converter motor which has high torque, High speed bearing from Europe, smoothly running and maintenance-free.
3.Multistage damping system, low noise and slight vibration,green.
4.Steel body, stainless steel centrifugal chamber, imports of key components,durable and easy to clean.
5.Overspeed, door interlock, imbalance protection. The rotor can be disinfected at high temperature & high pressure, ensure safety.
6.Proprietary air current design, small temperature-rise of centrifuge chamber,effective protection of the sample.
Technical Parameter:
Model |
TG18G |
Max Speed |
18000r/min |
Max RCF |
21500* g |
Max Capacity |
400ml |
Speed Accuracy |
±20r/min |
Time Range |
0-999min/sec |
Power Supply |
AC 220V 50Hz 18A |
Noise |
≤ 60dB |
Dimension |
400*350*340mm |
Weight |
25kg |
Rotors:
Rotor type |
No. |
Capacity |
Max speed (r/min) |
Max RCF (×g) |
Dimension of tube (mm) |
Fixed Angle Rotor |
6 |
12x1.5ml |
18000 |
21500 |
Φ10x42 |
9 |
24x1.5/2.0ml |
15000 |
21000 |
Φ10x42 |
|
12 |
10x5ml |
13000 |
11500 |
Φ14x54 |
|
22 |
6x50ml |
12000 |
14800 |
Φ28x105 |
|
30 |
8x15 |
10000 |
10300 |
Φ16x115 |
|
31 |
4x100ml |
10000 |
9690 |
Φ38x124 |
Rotor pictures:
Certifications of CE,ISO9001:2008,ISO13485:2003
FACTORY VIEWS:
