Specifications
centrifuge lab instrumenteasy to use
LCD&LED display,rotor identification&Brushless motor
wholesale price, fast delivery
CE
KH20R standard table laboratory centrifuge
Compact Benchtop Centrifuge lab instrument
1]Advanced Control System, Excellent separation
Ten kinds of Accel/Decel modes, can be selected; User can set up the operate parameter by themselves, to achieve the best centrifugal result.
Short running function, easy to diversification centrifugation.
Proprietary SCT speed control technical, high efficiency.
Proprietary SBT soft brake control technical, to avoid mix up and ensure get maximum specimen.
2]High Safety, Ease of use
Refrigerated lab centrifuge enjoy best price with rotor identification, no need to select rotor number.
Over temperature, over speed, door and unbalanced protection.
Steel body, Stainless steel chamber, Steel Protective sleeve.
Can take the rotor with aerosol-tight lid for use with hazardous samples.
3]Friendly Display, Humanity Operate
Refrigerated lab centrifuge with many pieces of LCD and LED display, the Program, Accel/Decel modes, RPM/RCF, Time, Temperature are all easy to set up.
Microprocessor control, operated data can be saved automatically, can start the instrument with RCF directly, can be store and use 40 kinds of self-defining operating modes directly by user-self.
4]Good parts, Reliable and longlasting
Brushless motor which has high torque, "SKF" supper speed bearing, Freon-free compressor from Europe.
Aerospace rubber for damping, super duralumin alloy from Aluminum Corporation of China Limited (CHALCO).
laboratory centrifuge Technical Parameter
Model |
KH20R |
Max Speed |
16600r/min |
Max Rcf |
19200×g |
Max Capacity |
300ml |
Speed Accuracy |
±20r/min |
Temperature Range |
-20°C-+40°C |
Temperature Accuracy |
±1°C |
Time Range |
1-999min |
Power Supply |
AC 220V 50Hz 15A |
Noise |
≤65dB |
Dimension |
600×570×370mm |
Weight |
90kg |
laboratory centrifuge Rotor
Model |
Number |
Capacity |
Max Speed (r/min) |
Max RCF(×g) |
(mm)Dimension of tube |
Angle Rotor |
No.1 |
12×1.5ml |
16600 r/min |
19200×g |
Φ10×42 |
No.2 |
18×0.5ml |
16600 r/min |
19200×g |
Φ8×32 |
|
No.3 |
24×1.5ml/2.0ml |
13000 r/min |
16060×g |
Φ10×42 |
|
No.4 |
48×0.5ml |
13000 r/min |
14740×g |
Φ8×32 |
|
| No.5 | 10×5ml |
13000 r/min |
11500×g |
Φ14×54 |
|
No.6 |
12×10ml |
12000 r/min |
14800×g |
Φ16×81 |
|
No.7 |
6×50ml |
11000 r/min |
14610×g |
Φ28×105 |
|
Microplate Rotor |
No.8 |
2×48Holes |
3000 r/min |
1400×g |
Microplate Rotor |
Product photos :
rotors:
Danfoss checking valve for centrifuge
SKF bearing in the power-driven machine for centrifuge
Compressor unit for centrifuge
Packing and delivery
