Home > Products > Pressure Vessel > cryogenic liquid nitrogen liquid oxygen dewar flask 175L
cryogenic liquid nitrogen liquid oxygen dewar flask 175L
- 20 Set / Sets per Month
- China mail port
- T/T Credit Card PayPal
- Spain-cryogenic shipping container KGSQ-liquid nitrogen storage system
- Chemical Sulphuric Acid Tank Trailer for Sale,V-Shape-Acid-Tanker-Trailer for exported
- IVF lab canes cryo freeze specimenliquid nitrogen dewar 47 liters YDS-47/127 with 10 canisters
- laboratory azot tank veterinary liquid nitrogen thermos to freeze semen 8l 10lter
- Bovine use transport liquid nitrogen tank nitrogen dryshipper horse semen 10 liter
- nitrogen cylinders sale used 30 litres wide open liquid nitrogen thermos for insemination
Product Details
Condition: | New | Capacity: | 175L | Place of Origin: | Hebei, China |
Brand Name: | bidragon | Model Number: | DPL450-175-2.0 | Dimension(L*W*H): | 508*1510MM |
Weight: | 119KGS | Certification: | ISO9001,CE,BV | Warranty: | 1 year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
cryogenic liquid nitrogen liquid oxygen dewar flask 175L
Welded insulated cylinders is a type of high vacuum drawn,multilayer heat insulating removable cryogenic liquid vessel
which can be applied to store, transport the liquefied gas products.
Stainless steel inside and outside the bile by high vacuum insulation sandwich, built-in vaporizer, pipeline valves and security systems and other components, welding insulation cylinder is stainless steel container, clean sanitation, no filling pollution, no bottled gas, water, air , rust, acid gas, fluorine plastics and other pollution, greatly improving the gas purity, can be widely used in machinery, shipbuilding, medical and chemical industry, electronics, bio-food, materials, energy and scientific research.
1,Mainly used in storage and transportation of liquid oxygen, liquid nitrogen, liquid argon, and liquefied natural gas
2,Adopted high multi-layer insulation method to ensure the low evaporation rate.
3,Inner vaporizer provides a 10Nm3/h stable continuous gas.
4,Solar installation use in the priority of gas-pressure and gas space.
5,Adopt the international CGA standard tie-in and all the valve installed imported from USA
6,Unique design of damping ring meets the needs of frequent transportation.
7,Suitable for electronics, research, chemical industry, welding, and LNG supply industries.
Specifications:
Cryogenic cylinder for sale
MODEL | DPL450-175-2.0 | DPL450-195-2.0 | DPL450-210-2.0 |
SIZE(diameter*height) MM
| 508*1510 | 508*1640 | 508*1730 |
WORKING PRESSURE(MPA) | 2.0 | 2.0 | 2.0 |
WORKING VOLUME(L) | 166 | 185 | 197 |
CRYOGENIC CYLINDER WEIGHT | 119 | 127 | 132 |
CAPACITY(O2) | 172KGS | 191KGS | 205KGS |
CAPACITY(N2) | 121KGS | 135KGS | 145KGS |
Any more questions,please sent inquiry below!!!
