Home > Products > Astronomical telescope > 160mm telescope
160mm telescope
- 200 Piece / Pieces per Month
- guangzhou
- T/T Credit Card
Product Details
Place of Origin: | Guangdong, China | Brand Name: | kson | Model Number: | Ekcentrik-W Np1605 |
Packaging Details
Nylon case
Product Description
Specifications
160mm telescope 25year telescope factory supply with lowest wholesale price, great160mm telescope
Model 3: | Ekcentrik-W Ekcel 1336 | |||||
Primary mirror | 133mm aperture, 800mm focal length, parabolic mirror with diffraction limited | |||||
resolution, higher reflectivity coating | ||||||
Tube: | Rolled Zinc-plated steel, with pearlized white finished | |||||
Mirror Cell | Stability treated die-cast Aluminum, provides better and stable alignment | |||||
Mounting System | Aluminum made deluxe dual mounting rings with vixen style plate | |||||
Focuser | 2" Standard Crayford focuser, with brass compression rings on 2" and 1.25" adaptor | |||||
Eyepieces | 1.25" Plössl 25mm and Plössl 10mm | |||||
Finder | Red dot finder with 30mm clear window and adjustable dim dot | |||||
Dimensions | 171 mm diameter main tube, OTA length 716mm, weights 5.6kgs | |||||
Nylon case(Optional) | Heavy duty padded Nylon case | |||||
Packaging Size | 1.16M3/10pcs | |||||
Shipping weight | 9Kgs | |||||
Resolution(Dawes Limit) | 0.872" | |||||
Limiting Magnitude | 12.62 | |||||
Max Magnification | 288x when the air is steady | |||||
Lightgathering power(vs naked eye) | 361 | |||||
Overall Package Size | 1.16M3/10pcs |
Mount type | wedge style EQ with goto | |||
Counterweight shaft length | 16MM | |||
Counterweight shaft material | 30MM | |||
Counterweight shaft diameter | Chrome-plated Steel | |||
Counterweight | 3 kgs | |||
Mount weight(without counterweight) | 6.5 kgs | |||
Mount height with extension | 350mm | |||
Mount adaptor | Vixen style | |||
Payload max | 8kgs (5.5kgs for photography) | |||
Total Weight(with counterweight) | 9.5kgs | |||
Motor Type | Microstep driven stepper motors | |||
Motor resolution | 0.148 arc sec(or 8,714,264 steps/rev) | |||
Gear ratio | 680.83 | |||
Speed Rate | 1x sidereal to 3 degree(720x) | |||
Material of mounts | All metal | |||
Power Supply | 12 V DC 2Amp | |||
Mount upgradeable | With wedge | |||
Controller | Ekstream GOTO controller 30 with 32,323 objects | |||
Level bubble | 8' accuracy level-bubble precision level adjustment and better goto performance | |||
Polar alignment scope | Easy to use red dot polar sight included | |||
Backlash Compensation | By software | |||
Tripod | stainless Steel legs with 1.5" and 1.25" tubes | |||
Tripod Height | 630mm-1080mm | |||
Accessory Tray | specially designed for enhance stablity of the tripod | |||
Countroller upgradeable | Via internet download |
Company Profile
KSON has been designing and manufacturing complete telescopes, riflescopes, optical products and optical accessories since our establishment in 1987. We not only offer a large range of optics products such as telescopes, riflescopes, red dots, binoculars, microscopes and all kinds of accessories for the above, but also offer the air guns and hunting accessories such as gun bipods, gun wood stocks, gun bags and cartridge bags, shooting glasses, and 12g and 16g CO2 cartridges. Now after 20 years of development, we have extended our products from the optics and hunting fields to the LED products
Kson has applied its optical mechanical electronic integration technical deposit and the advantage of human resource in manufacturing of significant green products LED, developed a product series of LED Constant-Current Direct-Drive high-power supply (LED CCDD power supply), which with independent patented technologies, product efficiency is more than 94%.
At the same time, Kson creatively applied its independent patented technologies relating to optical-mechanical-electronic integration technologies to take advantage of high-power LED devices characters, made nonlinear correction on light spots to get an ideal effect of clear hard-edge circular light spot, (eliminated floodlight jamming in light patch completely), so the products have higher illuminating efficiency, stronger condensation, longer range, more clear and uniform light patch, and natural, accurate color renditions of R, G, B and W.
All these condensation products cohered with Kson technical distillation are designers pursuit for expressing clear and smooth light, emphasizing intense condensing effect and pure circular light patch, it is an ideal choice for building a richer and colorful illuminating environment.
Our facility is located in Foshan City, Guangdong Province, covering an area of over 33,000 square meters. Our intent is to try our best to satisfy our clients' requirements and bring the high-quality products to the world. Now our products have been exported to North America, South America, Europe and Oceania.
Please feel free to contact us.
