Automatic Condom Cartoner Machine

Automatic Condom Cartoner Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Food, Beverage, Commodity, Medical, Chemical, Other, Food, Beverage, Commodity, Medical, Chemical, Machinery & Hardware
Packaging Type:
Cartons
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Food, Beverage, Commodity, Medical, Chemical, Other, Food, Beverage, Commodity, Medical, Chemical, Machinery & Hardware
Packaging Type Cartons
Packaging Material Paper
Automatic Grade Automatic
Driven Type Electric
Place of Origin Zhejiang, China
Brand Name huayuan
Model Number ZH-100

Specifications

1.Fully automatic horizontal cartoning machine.
2.Capacity:120boxs/min
3.Touch-sreen and PLC.
4.SS304



Automatic condom cartoner machine        Automatic condom cartoner machine

  Characteristic

  1. When material do not reach correct position, the pusher has an alarm and half facility for that, in order to ensure good quality of carton packaging and safety in operation effectively.
  2. Constantly moving carton-opening mechanism and pulling carton-opening mechanism are more stable and reliable.
  3. Vibrating material categorizing and feeding mechanism is stable and reliable.
  4. Half facility for air pressure and vacuum protection, when caster opened, the halt facility will be checked automatically for operating safety of the machine.
  5. It is easy, convenient and quick to change and adjust product size by hand wheel on instrument panel.
  6. Variable frequency speed regulation, PLC automatic control, Operating on the touch screen, words and numeric display, easy to operate, stable coefficients in operation.
  7. 8. Overload protection for principal driving, indication of failure diagnosis, and automatic halt of failure.
Main technical parameter

Electric power

 AC380V three-phrase and five-wire 50HZ total power 2.5kw

Production capacity

 Rotation speed  120b/min

Volume of consumption

 20m3 /h (pressure0.5-0.8Mpa)





Packing material

Box requirement

250-350g/m2

Specification

Max.Size:(LxHxW)200x80x50mm

Min.Size

Min Size: (LxHxW) 50x20x14mm

Overall dimension

3250x1450x1550mm

Weight

 About 1.2tons
