Specifications
1. suitable for Aluminum-Aluminumand Aluminum-plastic2.Blank frequency:15-30sheets
Capcity:3600-7200 sheets/hour
DPP-250E Automatic Packing Machine Equipment
Applications
The product uses the composite Aluminum film as material which has best performance of seal, proofing moisture and light, and uses special mould to cool-form. It is renewed packing equipment in pharmaceutical industry. The machine has two functions. When it changes mould, the machine can pack the object not only with Aluminum-Aluminum,but also Aluminum-plastic.
Performance and characteristic
Travel scope can be adjusted.
Mould is located by locating groove, so that it’s easy to change mould. Adopt cool-forming moulds.
Speed is shifted by step-less transducer. Adopt the interface of human-machine and PLC programmablecontroller.
Adopt photoelectric empty-detecting equipment and waster-eliminating equipment.
The heating moulds will automatically separate when the machine stops, which contributes to protect the material between them and extend the machine’s life.
Adopt the equipment of trace pressing, batch number printing and scarp-collecting.
Stepping motor drive wheel to grip and tow wrapper, Synchronize accurately
Main Technical Parameter
MODEL |
250E |
|
Blanking frequency(sheets) |
15-30 |
|
Sheet's quantity of one blanking(sheets) |
3-4 |
|
Capacity:(sheets/hour) |
3600-7200 |
|
Adjustable scope of feed travel:(mm) |
10-160 |
|
Max Forming area and depth:(mm) |
PVC(For medicine): |
240×160×15 |
Capacity of air compressor(m3/min) |
≥0.36 |
|
Power supply:(KW) |
380V 50HZ 5.5KW |
|
Wrapper specification(mm) |
Composite Aluminum film |
250×(0.11-0.15) |
Tropicalized Aluminum |
250×(0.02-0.035) |
|
Overall dimensions (mm) |
2800×700×1450 |
|
Part size (mm) |
1400×700×1450 |
|
1400×700×1450 | ||
Weight(kg) |
1200 |
|
