405nm 100mW Focusable Blue-Violet Line laser module
Conventional line lasers are adjusted in focus by rotating the line optics and inserting an focusing tool into the laser to adjust the position the collimating lens. This process make line rotating and also can result in the laser changing power classification. The unique focusing mechanism of our products allows the focus to be adjusted without the need for removing line optics by simply rotating the white ring of the laser. This novel design produces improved line quality whilst maintaining accurate alignment.
Line lengths from a few mm to several metres are available from a variety of standard optics, with custom optics to suit specialised requirements.
Specifications:
Specifications:
Wavelength:405nm
Output power:100mW
Laser class:II,IIIa,IIIb
Beam divergence:0.1mrad ~ 0.6mrad
Line thickness: Less then 2mm at 5m
Fan angle:10°~135°
Laser line accuracy:<30”(at 5m)
Operating Voltage:DC3V-5V
Dimensions:Φ16mm ×60mm,Φ16mm ×70mm
Operating Temperature:-10℃~70℃
Storage Temperature:-30℃~80℃
MTTF:8000 hours
Warranty:1 year
Applications:
Machine vision
Industrial inspection
Industrial marking devices
3D contour mapping
Positioning & visualization
Biomedical
High-end alignment
Laser targeting devices and so on..
Characteriscics:
High-quality laser diode,optical glass lens, driver circuit and housing
Better line quality
High reliability, high stability, long life,low price
