Tri-axle Fence Semi Trailer Yl9401ccy Stake Semi Trailer

Name: Tri-axle Fence Semi Trailer Yl9401ccy Stake Semi Trailer
Brand: CIMC
SKU: 109823231
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Type:

Semi-Trailer

Material:

Other

Certification:

Evangel (Shanghai) Industrial Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai/qingdao

Delivery Detail:

Delivery time depends on order quantity.

Type Semi-Trailer

Material Other

Certification CE

Size 13000x2500x3800

Max Payload 40ton

Place of Origin China

Brand Name CIMC

Model Number stake trailer

tri-axle fence semi trailer yl9401ccy stake semi trailer

Product Description

Features of tri-axle fence semi trailer yl9401ccy stake semi trailer

3 axle stake trailer cargo transport

FUWA 13ton axles

40ton load

radial tires

prifessional service

Parameters of tri-axle fence semi trailer yl9401ccy stake semi trailer

Type		Stake/Storage semi trailer
Shipping Terms		Shipping by containers or bulk cargo boat
Delivery time		13 workdays for one set stake/storage semi trailer
Weight:
	Tare Weight	5600kg--8500kg
	Loading Capacity	30T--60T
	Axle Weight Load	13T/16T
Specification:
	Axle number	Two or Three

	Suspension	Common mechanical Suspension
	Wheel	11.00R22.5/12.00R22.5 Vacunnm tire /Triangle or Double Cone Brand
	King Pin	JOST 50# or 90# traction pin
	Dimensions (LxWxH)	12450×2500×1490mm,1300024901450/1575/2770mm
	Support legs	28Tons
	Rim	8.25×22.5/9.00*22.5 Vacunnm tire Zhengxing Brand
	Wheelbase	5980+1300/6680/6260+1310+1310mm,
	Steel Spring	10/10/10 pieces per axles
	Twist Locks	4 pieces
Tire:
	Number of Tire	can be choose freely
	Spare Tire Carriers	2/4 pieces
Frame: (specs. and materials)
	The material of Main beam	The height of the beam is450/500mm,upper plate is 14mm,down plate is 16mm,middle plate is 8mm.If choose the SSAB high stress steel ,the uper and down plate is 8mm,middle plate is 5mm.
	Platform plate	3mm Diamond Plate
Brake:
	Brake	Kemi Brand of China
	Brake Chamber	Four double and two single chamber( TKL brand )
	ABS system	without
Electrical:
	Voltage	24V
	Receptacle	7 ways(7 wire harness)
