Telecom Accessories 10 pairs Krone Disconnection Module
1.Environment condition: -5-40 degree Celsius ;Relative humidity <85% (+30 degree Celsius);Atmospheric pressure: 70-106KPa ;
2.The modules are compatible with KRONE LSA-PLUS modules. The design of contacts basing on the principle of airtight contacting makes a completely reliable connection between the contacts and wires
3.Pulling-out force: tin bronze and silver plating (20-40 uinch), pulling-out force not less than 25N ;
4.Internal diameter of connection wire: 0.4-0.65 mm
5.The performance of anti-burn: PBT (UL94V-0)or anti-burn ABS (UL94V-0),Combustibility achieved GB/T 5169.7-1985 standard ;
6.Insulated resistance: under standard atmospheric pressure ,Insulated resistance no less than 1,000M ohm between the two disjunct connections ;
7.Intermediate resistance between the reed terminators: no more than 7m ohm between intermediate reed under the standard examination condition ;
8.Intermediate resistance: no more than 3m ohm under standard examination condition ;
9.Dielectric strength: according to industry standard
10.Specification:10 pairs, 8 pairs, 5 pairs
11.Type: disconnection types and connection types
12.insertion Life: 0.350.65mm conductor: 200 times 0.8mm conductor 50 times
Telecom Accessories 10 pairs Krone Disconnection Module
1.Environment condition: -5-40 degree Celsius ;Relative humidity <85% (+30 degree Celsius);Atmospheric pressure: 70-106KPa ;
2.The modules are compatible with KRONE LSA-PLUS modules. The design of contacts basing on the principle of airtight contacting makes a completely reliable connection between the contacts and wires
3.Pulling-out force: tin bronze and silver plating (20-40 uinch), pulling-out force not less than 25N ;
4.Internal diameter of connection wire: 0.4-0.65 mm
5.The performance of anti-burn: PBT (UL94V-0)or anti-burn ABS (UL94V-0),Combustibility achieved GB/T 5169.7-1985 standard ;
6.Insulated resistance: under standard atmospheric pressure ,Insulated resistance no less than 1,000M ohm between the two disjunct connections ;
7.Intermediate resistance between the reed terminators: no more than 7m ohm between intermediate reed under the standard examination condition ;
8.Intermediate resistance: no more than 3m ohm under standard examination condition ;
9.Dielectric strength: according to industry standard
10.Specification:10 pairs, 8 pairs, 5 pairs
11.Type: disconnection types and connection types
12.insertion Life: 0.350.65mm conductor: 200 times 0.8mm conductor 50 times
Guangzhou geleite Communication Science & Technology Co., Ltd was built in April, 1997. As a growing private hi-tech stock company, all of our staffs keep developing based on the management ideal of "regard customers as center, honest, creditable, more profit", now it has became a modern enterprise with high technology, strong production capacity, scientific management.
currently the products and services that company sales and offers are extended telecommunication, Unicom, CTT, electricity, China Mobile, nation defense, finance, education, stock, government and other large communication company, which receive widely reputation by clients.
The company owns over 3000 m2 factory area, with complete production facility, high accuracy processing, wealthy production and processing ability; exact testing equipment, complete testing project, complete office facility, achieve resource sharing and accelerate flow of information via intranet. The company set up functional department which can meet every management's demand plenty, it owns more than 200 well-trained management, operating and check staffs. All of the products developers and designers are of degree or above, close follow international advanced technology, scientific plot and control designing processing, adopt CAD to ensure our products' technology. The company continuous systemic training to ensure management and operating staffs' professional skill, so that meets the demand of enterprise manufacture
Company reception desk
Representatives of outstanding staff
Assemble
Install the Bunchy pigtail
Packing
Quality control workshop
Business license
Related qualifications
