Liugong Trailer Mounted Concrete Pump HBT60-9-75Z

Liugong Trailer Mounted Concrete Pump HBT60-9-75Z photo-1
US$ 15,000 - 56,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Power Type:
Diesel
Place of Origin:
China
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Power Type Diesel
Place of Origin China
Brand Name Liugong
Model Number HBT60-9-75Z
Power(W) 75 KW
Weight 5500kg
Dimension(L*W*H) 5850x2050x2260mm
Certification ISO/CE
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas
Product Description



Liugong Trailer Mounted Concrete Pump HBT60-9-75Z


1.Shangchai,  diesel engine and electrical motor
2.PLC control



Power system
World top brand diesel engine and electrical motor, strong power and low defect.

Control system
PLC program controller, well receive or send the signal expediently. It connects with the computer closely. When there is abnormal, it will recover the the original process.

Mixing system is driven by hydraulic motor. The hopper is unique in design, as assure that there is no accumulated material.



The pump is imported from Germany Rexroth, USA VICKERS. Big discharge, high efficiency, long span, and stable function and can run for a long period
lastingly.



No. Item Unit HBT60-9-75Z
1
Theory Concrete Output
(Low / High Pressure)
m3/h 60
2 Concrete Pressure
(Low / high pressure)
Mpa 9
3
Hydraulic system pressure
Mpa 32
4
Rotation speed
r/min 1480
5 High / low pressure switch   No
6 Distribution valve   Gate valve
7 Pumping cylinder diameter/ Stroke mm 205/1400
8 Main oil pump discharge ml/r 190
9 Motor power kw 75
10 Voltage/ Frequency V/Hz

380/50

11 Hydraulic tank volume L 500
12 Height of adding material mm ≤1500
13 Hopper volume m3 0.7
14 Total mass kg 5500
15 Concrete slump mm 80-230
16 Theory vertical pumping height m 100
17
Theory direction change times
Low/High pressure
times/min 22
18 Dimension: LXWXH mm 5850×2050×2260
