LiuGong new Hold Concrete Pump 48 M with Good Quality
Feature
Advantages and innovation
- Design: Machinery, electrical and hydraulic one system.
- Part supplier: Some parts from World Top brand to assure high configuration and quality and liablilty.
- Main Power: World Top Brand supplier: Shangchai diesel engine; the key part hydraulic pump and hydraulic valve; The pump is imported from Germany Rexroth, USA VICKERS. The pipe joint and hydraulic oil pipe are from USA and Italy.
- Control parts: Electrical control way is Siemens technology. The key component parts are from world top suppliers, as improve the stability and liability.
- Pumping process: Start the machine then dial pumping button. The rotation of the machine can be tracked automatically according to instruction, to reach the minimum working 1300r/min. If it needs to add the pumping discharge, just dial the electrical button, the machine will runs according to instruction.( Weichai engine)
Parameter
Liugong Concrete Pump Specification:
CONCRETE PUMP CHASSIS
Chassis Model CYH51Y
Emission Stage Euro III
Engine Power 287 kw
Engine Displacement 11.946 L
Driving Type 8*4
Wheelbase 1850+4605+1310 mm
Max. Running Speed 89 km/h
Min. Turning Radius 11.9 m
Approach/Departure Angle 18.7/10.2°
Tyre Type 295/80R22.5
Concrete pump BOOM SYSTEM
Max. vertical reach 47.2 m
Max. horizontal reach 43.2 m
Reach depth 33.7 m
Unfolding height 9.3 m
Boom control mode Manual,wire and wireless remote control are all available
Boom type RZ
Boom section articulation 90/180/180/180/265
90/180/180/180/240
Slewing range 365°
Front Outriggers spread 8800 mm
Rear Outrigger spread 10030 mm
End hose length 3 m
Arm attached pipeline diameter 125 mm
CONCRETE PUMP DIMENSIONS&WEIGHT
Overall Length 12700 M
Overall Width 2490 M
Overall Height 3990 M
Overall Net Weight 38000 KG
