Mounted Mould Board Plough
USD $200 - $800
/ Piece
100 Pieces(Min.Order)
- Mumbai
- T/T L/C D/P D/A
You May Like
Product Details
| Use | Tractors | Place of Origin | Punjab, India | |
| Brand Name | Brohawk | Model Number | BMBP-200 |
Product Description
Mounted Mould Board Plough
- It can handle the toughest ploughing job with outstanding penetration performance.
- It is designed to work in all types of soil for basic functions such as soil breaking, soil raising and soil turning.
- It can be used in stony & rooted soils.
- The under-frame and unit-to-unit clearance are adequate to cope with trashy conditions.
- Adding an extra furrow or repositioning units to allow for extra clearance is quick and easy.
- The plough has special wear-resistant steel bottoms with bar points for toughest ploughing jobs.
- Bar point bottoms ensure longer life as they can be extended or reversed and re-used till the last possible length.
Specification:
MODEL NO | BMBP-200 | BMBP-300 |
SIZE | 2 FURROW | 3 FURROW |
FRAME | 65X65x8 mm Box & 50mm Round | 65X65x8 mm Box & 50mm Round |
TYNES | 36 mm Profile cut Single Piece | 36 mm Profile cut Single Piece |
LENGTH | 1300 mm | 1880 mm |
WIDTH | 738 mm | 738 mm |
HEIGHT | 1066 mm | 1066 mm |
BLADE | 10 mm | 10 mm |
MOULD BOARD | 8 mm | 8 mm |
SHOVEL | 40×25 mm Bar (EN-42 Forged) | 40×25 mm Bar (EN-42 Forged) |
3 POINT LINKAGE | 65×16 mm Flat & 31 mm Square | 65×16 mm Flat & 31 mm Square |
CLAMP | 125×50 mm | 125×50 mm |
WIDTH OF CUT (B) | 610mm (max) | 910mm (max) |
DEPTH OF CUT | 350mm (max) | 350mm (max) |
WEIGHT | 235 Kg. (approx) | 350 Kg. (approx) |
POWER REQUIRED (HP) | 30-40 | 55-60 |
