Agilent HP 8970B Niose Figure Meter
Product Description
- Simultaneous noise figure and gain measurements
- Easy characterization of amplifiers and frequency converting devices
- Noise figure measurement range: 0 to 30 dB
- Gain measurement range: -20 to >+40 dB
- Input frequency range: Tunable from 10 to 1600 MHz, with option 2047 MHz
- Input noise figure: <7 dB +0.003 dB/MHz
- Maximum net external gain: >65 dB
- Bandwidth: ~4 MHz
- Audible noise level: <5.5 bels at 1 meter
- Measurement speed: 6 to 9 measurements per second with minimum smoothing
- Sweep speed at minimum smoothing (10 to 1600 MHz): 140 ms per frequency point
- Maximum safe input level: ±20 Vdc, +20 dBm peak (or average) at RF
- Displayed measurement frequency range: 10 to 99999 MHz
- Number of calibration points in one sweep: 181
