S900 Handheld Mobile Payment Terminal
PAX S900 is the world’s most innovative wireless mobile payment terminal based on a secure and flexible Linux operating platform.
Combining a wide choice of connectivity options along with long-lasting battery performance, The S900 features inbuit NFC capability to accept mobile and contactless transactions, a large colour touch screen, a 32-bit ARM11 processor and massive amounts of memory via Micro SCD for exceptional multimedia performance such as video advertising.
Powered by PAX Prolin, the POS operating system based on Linux, this platform supports rapid development of customized and secure software applications that give new meaning to the concept of payment and other value-added services.
Features
High Reliability & Exceptional Performance
400MHz 32-bit ARM11 processor
Multiple connectivity options:GPRS/WCDMA/EVDO
Built-in contactless / NFC
Advanced DDR & SDRAM technology
Sleek compact design with concealed thermal printer
High capacity Li-ion rechargeable battery
Supports e-Signature functionality
Multimedia performance
Loudspeaker
Large colour touch screen display
Supports HD images and video
Open & flexible operating system
Secure Prolin Linux platform
Easy software application development
User-friendlu interface with powerful GUI
Multi-task OS maintains application integrity
Plug-and-Play to extend functionality on-site
Unprecedented Security
PCI PTS 3.x approved
Secure embedded area for keys, self-destruct mechanism if attached
Supports RSA, AES, DES, #DES
Supports HASH function
Suppots DUKPT, MK/SK, FIXED KEY
SPECIFICATIONS
Processor
32-bit ARM11
Memory
192MB(128MB Flash, 64MB DDR)
Display
3.5 inch color TFT LCD
Printer
Thermal graphic printer
High-speed thermal printer (18 lps)
Paper roll width 58m diameter(standard)
Keypad
10 numeric & 5 function keys
Back-lighting
Magnetic card reader
Triple track(Track1 / 2 / 3),
Bi-directional
Smart card reader
EMV 4.3
Contactless card reader
MasterCard PayPass 3.0 & Visa payWave
13.56MHz, ISO14443, Type A / B, Mifare, Felica, NFC
Maximum effective distance up to 4cm
Communication
GPRS
WCDMA/EVDO(optional)
Dual-SIM GPRS(optional)
Vedio
Speaker 100dB
Card slots
2 SAM slots, ISO7816
1 SIM card
Peripheral Ports
1 Multi-function port(USB OTG+RS232)
1´ powerful charge
1´ base station port
Security
DUKPT, Master/session, DES, 3DES
ANSI /ISO9564 format 0, 1, 3
PIN ciphered key algorithm
ANSI ´9.9/ ´9.19 MAC algorithm
Environmental
0°C ~ 50°C (32°F ~122°F) operating temperature
-20°C ~ 70°C (-4°F ~158°F) storage temperature
10% ~ 90% relative humidity, non-condensing
Voltage
Battery, 7.4V, 1850mAH, Li-ion
Input: 100 - 240V AC, 50/60 Hz, 1A
Output: 9V, 2.5A
Adapter & base
Physical (L x W x H)
175mm x 82mm x 63mm
Weight
458g with battery
Certifications
PCI PTX 3.X
EMV 4.3
MasterCard PayPass3.0
Visa payWave
Note:Supply only for Chile , Uruguay, Paraguay , Surinam and some other countries where there is no PAX distributors
