PAX S800 Countertop payment terminal

Specifications

1.Large memory capacity
2.Large, white backlit display
3.High-speed thermal printer
4.Multi-application support
5.Large capa



S800 COUNTERTOP PAYMENT TERMINAL







PAX’s S800 is the world’s most innovative countertop payment terminal powered by PAX Prolin based on a secure and flexible Linux operating platform. This platform supports rapid development of customized and secure software applications that give new meaning to the concept of payment and other value-added services.







The S800 comes in a compact and stylish form factor, equipped with a large colour screen and Loudspeaker. Combining a wide choice of connectivity options, the GS800 features inbuilt NFC capability to accept mobile and contactless transactions. With a 32-bit ARM11 processor and massive amounts of memory via Micro SD, the S800 supports exceptional multimedia performance such as video advertising.







FEATURES



High reliability & exceptional stability



400MHz 32-bit ARM11 processor



Multiple connectivity - Dial-up / Ethernet / GPRS / WCDMA



Built-in contactless / NFC



High-speed thermal printer (25 lines per second)



Various ports for perfect expansibility



Advanced DDR & SDRAM technology



Sleek compact design







Open & flexible operating system



Secure Prolin Linux platform



Easy software application development



User-friendly interface with powerful GUI



Multi-tasking OS maintains application integrity



Plug-and-Play to extend functionality on-site







Unprecedented security



PCI PTS 3.x approved



Secure embedded area for keys, self-destruct mechanism if attacked



Supports RSA, AES, DES, 3DES



Supports HASH function



Supports DUKPT, MK/SK, FIXED KEY







Multimedia performance



Loudspeaker



Large colour screen display



Supports HD images and video



SPECIFICATIONS

Memory	192MB standard (128MB Flash, 64MB SDRAM) Optional Micro SD (TF card) up to 32GB
Display	2.8 inch 320 x 240 pixel TFT colour LCD
Magnetic Card Reader	Track 1/2/3, bidirectional
Smart Card Reader	1 user card, EMV 4.3
Card Slots	3 SAMs / SIM, ISO7816
Contactless Card Reader	MasterCard PayPass 3.0 & Visa payWave 13.56MHZ, ISO14443 Type A/B, Mifare, Felica, NFC Maximum effective distance up to 4cm



















  Supplied Place :  Argentina, Uruguay, Paraguay
