The so-called slip ring is an electrical component responsible for rotator connectivity, energy and signal’s transport. According to the transmission medium, slip ring is divided into conductive ring, fluid slip ring, and smooth ring. Also referred to as “rotation connectivity” or“spin-pass. Usually slip ring is installed in the center of rotation of equipment, mainly composed of two parts of rotating and stationary. Rotation structure of rotary part is connected with the use of the equipment and subsequent operation, it is called rotor; connecting the fixed structure of the device, it is called stator. Overall slip ring rely on stretch lap principle, the principle of rolling lap, or sealing principle, and clever movement structure and seal design, precision parts production with a reasonable selection, which form a stable and reliable connectivity rotation system. As long as the slip ring attached to the unlimited rotating equipment, we can provide the power and energy to the rotating body, while endless rotary movement, but also for other movement, or detect the working condition under the rotation state
Specification |
Unit |
Rings |
6wires |
Current value |
6wiresX 130A |
Voltage |
0-380V DC |
Lead type |
Colour coded, silver plated, PTFE insulated lead wires |
Lead length |
200mm (other lengths on request) |
Dielectric strength |
500VAC @ 50Hz |
Insulation Resistance |
≥1000MΩ/500VDC |
Dynamic contact Resistance |
≤0.01Ω |
