Non Woven Calender Making Machine Just for Plain Nonwoven

Specifications

the parts of the calender

a rack, embossing roller device, smooth roller device, transmission device, shell device, lubricating and cooling device, a hydraulic device, cooling roller  device, web forming roller device and electric cross device

the most use of the machine :

This machine is mostly used for spinning web, fusion spray cloth, staple  fiber carding, longitudinalrelaxation and tension to the nonwoven fabric.to emboss nonwoven  to make different kinds of pattern or make plain .

  Detailed Product Description

 1) calender roller material: alloy steel  48crmo
2) calender roller with mirror

3) independent heating system with oil or electralic


Features:

 1) adopt best quality alloy stainless steel 48crmo

2) independent heating system

3) one machine three roller driving or one machine two rollers

4) roller bearing,equip lubrication cooling station

5) steel plate,fine machined by heat treatment

6) max working width: 6000mm

7) max nip pressure 100kg/cm

8) cross central height compensation

9) newest bend central height compensation

10) solve the problem by special method according to the special requirements from user

information:

1)Roll material: high quality alloy steel 48crmo

2) Roller specification: roll diameter: 380mm-850m
 3)The form of heating: roll peripheral holes are arranged, the heating speed, even temperature of roller surface

4) Roller specification: roll diameter: 380mm-750mm

 5)The largest width: 6000mm

6) Maximum speed: 30m/min

7) The mill top line pressure: 100kg/cm

8) Rolling mill drive mode: a machine with a stick or a machine with two rollers

 9)Roll center cross adjustable, adding roll curve

 Rolling mill bearing with double row cylindrical roller bearings, with thin oil lubrication

 10)The new hydraulic pull bending high compensation

 smooth rollers:

different kinds of parts and processing machines:

loading machine :

Our USP (Unique selling point):

   Our factory is specializing in manufacturing and exporting  PP Spunbond Nonwoven Fabrics machines with high quality and pretty competitive price.FREE nonwoven fabric SAMPLE will be sent for your evaluation

1)    Own factory and professional manufacturer

2)    Reasonable price

3)    Implement strict quality testing and control procedure to make superior quality

 4)    Years of export experience

 5)    Customized color and logo are acceptable

6)    Best service and punctual delivery
